Kawasaki KLX150L (Latin America) Front Fork Diagram

#

Description
Price

132

BOLT-FLANGED-SMALL,8X35

132BA0835

$4.76

44008

PIPE-FORK OUTER,RH,P.SILVER

44008-0065-458

$231.89

44008A

PIPE-FORK OUTER,LH,P.SILVER

44008-0074-458

$231.89

44013

PIPE-FORK INNER

44013-0247

$196.34

44022

CYLINDER-FORK

44022-0020

$64.34

44024

CAP-OIL-LOCK

44024-1067

$22.60

44025

RING-FORK PISTON

44025-1065

$10.21

44026

SPRING-FRONT FORK

44026-0179

$44.75

44026A

SPRING-FRONT FORK

44026-1417

$3.89

44037

HOLDER-FORK UNDER,P.SILVER

44037-0138-458

$254.15

44039

HOLDER-FORK UPPER,P.SILVER

44039-0083-458

$156.48

44045

GASKET,FORK CYLINDER BOLT

44045-051

$6.16

44065

BUSHING-FRONT FORK,INNER PIPE

44065-0053

$22.76

44065A

BUSHING-FRONT FORK

44065-1133

$17.60

44071B

DAMPER-ASSY,RH,P.SILVER

44071-1302-458

$448.64

44071C

DAMPER-ASSY,LH,P.SILVER

44071-1303-458

$448.64

49006

BOOT,FORK,BLACK

49006-0583-BD

$61.13

92001

BOLT,FORK CYLINDER

92001-1464

$6.22

92026

SPACER

92026-1365

$9.73

92049

SEAL-OIL,FORK OUTER TUBE

92049-1524

$17.76

92055

RING-O,FORK TOP

92055-1367

$5.74

92072

BAND,BOOT

92072-0107

$11.93

92151

BOLT,FORK TOP

92151-1262

$39.08

92154

BOLT

92154-1169

$10.49

92200

WASHER

92200-1496

$6.00
