Kawasaki KLX®250 Fuel Tank Diagram

#

Description
Price

11056

BRACKET,ADJUSTER,LH

11056-1452

$6.00

11056A

BRACKET,ADJUSTER,RH

11056-1457

$6.00

51001

TANK-COMP-FUEL,F.S.BLACK

51001-0294-25Q

$913.69

51001A

TANK-COMP-FUEL,F.S.BLACK

51001-0297-25Q

$942.07

51049

CAP-TANK,FUEL

51049-0049

$108.49

53044

TRIM,L=490

53044-1209

$14.17

92022

WASHER,6.5X24X2

92022-1690

$3.92

92022A

WASHER,5.1X10X1.0

92022-1977

$3.65

92075

DAMPER,9X24X14

92075-281

$6.22

92093

SEAL,FUEL TANK CAP

92093-1030

$7.77

92143

COLLAR,6.8X10X24.5

92143-1459

$4.39

92152

COLLAR,6.5X10X18

92152-1560

$5.05

92160

DAMPER,FUEL TANK,RR

92160-1254

$10.65

92160A

DAMPER,FUEL TANK

92160-1328

$7.34

92161

DAMPER,10X16X15

92161-1397

$4.10

92170

CLAMP

92170-1492

$5.00

92170A

CLAMP,TUBE

92170-1834

$4.67

92192

TUBE

92192-0604

$10.67

92192A

TUBE,7X12X700

92192-0778

$13.06

92200

WASHER,6.5X18X1.6

92200-0766

$1.63

130

BOLT-FLANGED,6X10

130BB0610

$2.49

130A

BOLT-FLANGED,6X25

130BB0625

$2.80

132

BOLT-FLANGED-SMALL,6X35

132BA0635

$2.06

220

SCREW-PAN-CROS,5X10

220AA0510

$0.71

92170A

CLAMP,TUBE

92170-1834

$4.67

92192A

TUBE,7X12X700

92192-0778

$13.06
