2022 Kawasaki KLX®230 S Crankcase Diagram

← All diagrams

Find the part on the Crankcase diagram for your 2022 Kawasaki KLX®230 S, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2022 Kawasaki KLX®230 S Crankcase Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11061

GASKET,10.5X16X2

11061-0222

1

$4.44

In stock

14001

SET-CRANKCASE

14001-0707

1

$284.32

In stock

16130

VALVE-ASSY-RELIEF

16130-0002

1

$23.95

In stock

21176

SENSOR,SPEED

21176-0894

1

$183.12

In stock

92001

BOLT,W/WASHER,6X14

92001-1829

1

$3.53

In stock

92022

1

$4.17

In stock

92043

PIN,6.2X8X14

92043-1741

1

$2.95

In stock

92045

1

$24.19

In stock

92045A

BEARING-BALL,6306CM

92045-0907

1

$43.98

In stock

92045B

1

$15.63

In stock

92045C

BEARING-BALL,6204C3

92045-0909

1

$19.69

In stock

92045D

1

$31.38

In stock

92045E

BEARING-BALL,6203C3

92045-0911

1

$14.53

In stock

92045F

1

$16.88

In stock

92046

1

$13.53

In stock

92049

SEAL-OIL,32X45X7.5

92049-0825

1

$20.69

In stock

92049A

SEAL-OIL,TC14245

92049-1520

1
Out of stock

92055

RING-O,OD=13

92055-074

1

$6.82

In stock

92055A

RING-O

92055-0958

1

$8.05

In stock

92055B

RING-O,5.5X1.5

92055-1339

1

$3.85

In stock

92062

NOZZLE

92062-0050

1

$23.02

In stock

92062A

NOZZLE,8X8

92062-0567

1

$3.49

In stock

92062B

NOZZLE,6X8,SILVER

92062-1081

1

$5.63

In stock

92066

PLUG,DRAIN

92066-0978

1

$3.76

In stock

92143

COLLAR

92143-1263

1

$4.32

In stock

92150

BOLT,SOCKET,5X20

92150-1019

1

$3.61

In stock

92154

BOLT,6X50

92154-1168

1

$0.93

In stock

92154A

BOLT,RETURN SPRING

92154-1306

1

$8.51

In stock

92154B

BOLT,FLANGED,6X30

92154-2758

1

$2.76

In stock

92154C

BOLT,FLANGED,6X70

92154-2764

1

$3.51

In stock

92154D

BOLT,FLANGED,6X65

92154-2766

1

$3.15

In stock

92154E

BOLT,FLANGED,6X16

92154-2895

1

$1.10

In stock
