Handlebar
Kawasaki KLX®230 DF ABS Handlebar Diagram
#
13280
HOLDER,LEVER
13280-0929
$40.04
13280A
HOLDER,MIRROR
13280-0930
$21.13
13280B
HOLDER,MIRROR
13280-1000
$22.11
27010
SWITCH,CLUTCH
27010-0729
$32.97
35063
STAY,HANDLE COVER,RH
35063-1616
$21.92
35063A
STAY,HANDLE COVER,SIDE,LH
35063-1663
$18.11
35063B
STAY,HANDLE COVER,SIDE,RH
35063-1664
$18.11
35063C
STAY,HANDLE COVER,LH
35063-1665
$21.92
39156
PAD,89X18
39156-2968
$2.83
46003
HANDLE,FAT TYPE BAR
46003-0860
$260.73
46012
HOLDER-HANDLE,UPP,F.S.BLACK
46012-0449-18R
$22.63
46012A
HOLDER-HANDLE,LWR,F.S.BLACK
46012-0450-18R
$28.70
46019
GRIP-ASSY,THROTTLE
46019-0129
$35.66
46075
GRIP,LH
46075-0692
$27.72
46076
LEVER-ASSY-GRIP,CLUTCH
46076-0206
$111.63
46091
HOUSING-ASSY-CONTROL,RH
46091-0687
$138.39
46091A
HOUSING-ASSY-CONTROL,LH
46091-0717
$143.21
46092
LEVER-GRIP,CLUTCH
46092-0591
$26.22
53044
TRIM,L=85
53044-0556
$12.58
56001
MIRROR-ASSY
56001-0419
$45.64
59441
COVER-HANDLE,LH,M.C.GRAY
59441-0313-67K
$28.21
59441A
COVER-HANDLE,RH,M.C.GRAY
59441-0314-67K
$28.21
92009
SCREW,CABLE ADJUST,8MM,BLACK
92009-1134
$15.16
92015
NUT,LOCK,6MM,BLACK
92015-1191
Unavailable
92015A
NUT,CABLE ADJUST LOCK,8MM,BLK
92015-1197
$9.91
92022
WASHER,10.2X28X2
92022-1088
$4.69
92037
CLAMP,SPEED,L=80.5
92037-1903
$7.84
92152
COLLAR
92152-3982
$10.49
92154
BOLT,UPSET,6X22
92154-1422
$4.69
92154A
BOLT,17X18
92154-1902
$18.95
92154B
BOLT,FLANGED,6X44
92154-2331
$7.59
92154C
BOLT,FLANGED,8X30
92154-2655
$2.00
92154D
BOLT,BAR END
92154-7319
$10.39
92154E
BOLT,SOCKET,6X16
92154-7346
$2.92
92161
DAMPER,12X26X19
92161-2116
$6.07
92172
SCREW,3X16
92172-0183
$2.15
92172A
SCREW,5X12
92172-0857
$0.63
92173
CLAMP
92173-2199
$1.48
92173A
CLAMP,HANDLE,UPP,LH
92173-2845
$7.28
92173B
CLAMP,HANDLE,UPP,RH
92173-2846
$7.28
92173C
CLAMP,HANDLE,LWR
92173-2847
$5.68
92200
WASHER,12.5X27.6X1.2
92200-0872
$5.52
92200A
WASHER,6.5X11.5X0.8
92200-0947
$0.39
92210
NUT,LOCK,10MM
92210-1672
$4.60
120
BOLT-SOCKET,6X25
120CB0625
$2.62
220
SCREW-PAN-CROS,5X22
220AB0522
$1.11
220A
SCREW-PAN-CROS,5X40
220AB0540
$2.06
221
SCREW-CSK-CROS,5X10
221AB0510
$4.51
410
WASHER-PLAIN-SMALL,6MM
410AB0600
$0.77
