Kawasaki KLR™650 Carburetor(CA) Diagram

#

Description
Price

11044

BRACKET,THROTTLE CABLE

11044-1353

$59.62

13091

HOLDER,NEEDLE JET

13091-1425

$29.68

14025

COVER,MIXING CHAMBER

14025-1890

$77.81

14025A

COVER,AIR CUT VALVE

14025-1903

$58.45

15004

CARBURETOR-ASSY,CVK40

15004-0072

$774.13

16007

SEAT-SPRING,DIAPHRAGM VALVE

16007-1113

$20.77

16014

SCREW-PILOT AIR

16014-1083

$22.90

16016

PLUNGER

16016-1087

$88.75

16017

JET-NEEDLE,#6

16017-0055

$48.10

16021

SCREW-THROTTLE STOP

16021-1201

$46.93

16030

VALVE-FLOAT

16030-1057

$47.13

16031

FLOAT

16031-1077

$53.59

16044

CLAMP,FLOAT VALVE

16044-007

$7.91

16187

NEEDLE-JET,N6NJ

16187-0275

$36.91

43028

DIAPHRAGM,5.9MM,AIR CUT VALVE

43028-0016

$80.05

43028A

DIAPHRAGM,VALVE

43028-1062

$210.38

49019

FILTER-FUEL

49019-1097

$9.23

92005

FITTING,FUEL,T-TYPE

92005-1112

$14.10

92009

SCREW,5X10

92009-1365

$7.34

92009A

SCREW,DRAIN,M6X0.75

92009-1551

$9.91

92037

CLAMP,12.5MM

92037-1271

$2.79

92037A

CLAMP,TUBE

92037-1477

$4.31

92055

RING-O,FLOAT CHAMBER

92055-1222

$17.44

92055A

RING-O

92055-1245

$5.57

92063

JET-MAIN,#140

92063-1013

$14.10

92063B

JET-MAIN,#145

92063-1017

$14.10

92063D

JET-MAIN,#150

92063-1330

$14.10

92064

JET-PILOT,#40

92064-1108

$17.03

92066

PLUG,PILOT AIR SCREW,6.9X2

92066-1051

$5.05

92081

SPRING,DIAPHRAGM VALVE

92081-1718

$27.69

92081A

SPRING,AIR CUT VALVE

92081-1719

$12.62

92173

CLAMP

92173-1190

$2.55

92192

TUBE,FUEL,6.2X13.2X170

92192-0453

$27.47

92192A

TUBE,5X9X40&20

92192-0480

$17.13

92192B

TUBE,L=70

92192-0588

$15.35

92192C

TUBE,L=360

92192-0589

$29.37

220

SCREW-PAN-CROS,4X14

220AA0414

$4.60

223

SCREW-PAN-WS-CROS,4X8

223C0408

$1.20

225

SCREW-PAN-WSP-CROS,4X18

225AB0418

$4.34

92063A

JET-MAIN,#142

92063-1016

$14.10

92063C

JET-MAIN,#148

92063-1324

$14.10
