Kawasaki KFX90 Carburetor(A7F) Diagram

#

Description
Price

13271

PLATE

13271-Y001

Unavailable

13280

HOLDER,NEEDLE JET

13280-Y005

$37.73

15003

CARBURETOR-ASSY

15003-Y002

$291.35

16005

TOP-CHAMBER

16005-Y001

$29.48

16017

JET-NEEDLE

16017-Y001

$33.66

16020

CHAMBER-FLOAT

16020-Y001

$101.58

16021

SCREW-THROTTLE STOP

16021-Y001

$3.54

16021A

SCREW-THROTTLE STOP,ASSY

16021-Y002

$4.53

16025

VALVE-THROTTLE

16025-Y001

$99.72

16030

VALVE-FLOAT,ASSY

16030-Y002

$18.69

16031

FLOAT

16031-Y001

$46.88

16157

JET-STARTER

16157-Y001

$115.97

16158

JET-SLOW

16158-Y001

$14.87

23013

SCREW-ASSY,ADJUST

23013-Y001

$3.55

92033

RING-SNAP

92033-Y003

$1.87

92043

PIN

92043-Y002

$1.76

92055

RING-O

92055-Y001

$1.71

92055A

RING-O

92055-Y016

$1.76

92063

JET-MAIN

92063-Y001

$21.43

92145

SPRING

92145-Y002

$2.30

92145A

SPRING

92145-Y004

$0.79

92172

SCREW,DRAIN

92172-Y001

$4.66

92172A

SCREW

92172-Y012

$0.82

92172B

SCREW

92172-Y013

$0.71

92172C

CLAMP

92172-Y023

$1.29

92192

TUBE,ASSY

92192-Y003

$6.62

92192A

TUBE,ASSY

92192-Y006

$3.12
