Kawasaki KFX®90 Gear Change Drum/Shift Fork(s) Diagram

Description

Price

11061

GASKET,GEAR CASE

11061-Y016

$5.42

13107

SHAFT,FINAL

13107-Y004

$85.91

13234

SHAFT-COMP

13234-Y001

$79.76

13271

PLATE

13271-Y007

$1.63

14026

COVER-CHAIN

14026-Y001

$9.39

14055

CASE-GEAR

14055-Y001

$153.41

16085

GEAR,FINAL

16085-Y004

$54.93

39134

SPROCKET-DRIVE

39134-Y001

$20.95

39159

SHAFT-DRIVE

39159-Y001

$73.34

92033

RING-SNAP

92033-Y011

$1.15

92043

PIN,BRAKE

92043-Y001

$11.17

92043A

PIN,DOWEL,10X20

92043-Y014

$1.11

92045

BEARING-BALL,6201

92045-Y002

$28.93

92045A

BEARING-BALL,6004 UU

92045-Y005

$22.42

92049

SEAL-OIL,27X42X7

92049-Y008

$2.85

92055

RING-O,7.5X1.5

92055-Y002

$0.78

92057

CHAIN,DRIVE

92057-Y004

$38.38

92153

BOLT,6X10

92153-Y014

Unavailable

92153A

BOLT,FLANGE,6X10

92153-Y045

$0.95

92200

WASHER,12MM

92200-Y004

$5.24

92200A

WASHER,15MM

92200-Y007

$1.00

92210

NUT,8MM

92210-Y014

$1.23
