Kawasaki KFX®90 Frame Diagram
#
Description
Price
14073
DUCT
14073-Y001
$19.00
31064
PIPE-COMP,FRONT BUMPER,SILVER
31064-Y001-938
$53.33
31064A
PIPE-COMP,FRONT BUMPER,SILVER
31064-Y002-938
Unavailable
32109
GRIP-FRAME,RR
32109-Y002
$105.75
32109A
GRIP-FRAME,RR
32109-Y004
$113.29
32160A
FRAME-COMP
32160-Y002
Unavailable
32190
BRACKET-ENGINE,RH
32190-Y001
$14.42
32190A
BRACKET-ENGINE,LH
32190-Y002
$14.42
35063
STAY,FR
35063-Y002
$12.58
35063A
STAY,REAR FENDER,RH
35063-Y004
$9.49
35063B
STAY,REAR FENDER,LH
35063-Y005
$9.49
92045
BEARING-BALL,6002
92045-Y009
$12.67
92049
SEAL-OIL,18X32X7
92049-Y003
$2.20
92049A
SEAL-OIL,22X35X7
92049-Y005
$2.51
92072
BAND
92072-Y003
$1.90
92092
BUSHING-RUBBER
92092-Y001
$5.18
92152
COLLAR
92152-Y009
$5.81
92153
BOLT,FLANGE,6X12
92153-Y023
$0.76
92153A
BOLT,FLANGE,8X12
92153-Y031
$1.90
92153B
BOLT,FLANGE,8X16
92153-Y032
$1.47
92153C
BOLT,FLANGE,10X70
92153-Y043
$3.20
92153E
BOLT,FLANGE,8X40
92153-Y069
$2.51
92161
DAMPER
92161-Y006
$1.40
92171
CLAMP
92171-Y004
$3.55
92171A
CLAMP
92171-Y009
$2.30
92210
NUT,10MM
92210-Y009
$3.12
92210A
NUT,FLANGE,8MM
92210-Y032
$1.63
