Description

Price

11065

CAP,WHEEL

11065-Y002

$3.69

16126

VALVE,RIM

16126-Y001

$6.55

21083

ARM,BRAKE,RH

21083-Y001

$11.14

21083A

ARM,BRAKE,LH

21083-Y002

$11.14

41009

TIRE

41009-Y002

$94.48

41025

RIM,SILVER

41025-Y002-936

$79.10

41035

PANEL-ASSY-BRAKE,FR,RH,SILVER

41035-Y001-934

$57.62

41035A

PANEL-ASSY-BRAKE,FR,LH,SILVER

41035-Y002-934

$57.62

41036

HUB-ASSY,FR,SILVER

41036-Y002-936

$66.96

41047

SHOE-ASSY-BRAKE,FR

41047-Y001

$27.98

41050

CAM-BRAKE

41050-Y001

$13.25

92045

BEARING-BALL,6002

92045-Y010

$13.39

92045A

BEARING-BALL,6003

92045-Y011

$16.50

92093

SEAL,22X35X7

92093-Y008

$1.65

92145

SPRING,BRAKE SHOE

92145-Y013

$3.12

92145A

SPRING,RETURN

92145-Y014

$1.91

92152

COLLAR

92152-Y008

$2.85

92152A

COLLAR

92152-Y009

$5.81

92153

BOLT,STUD,10X17

92153-Y017

$3.17

92153A

BOLT,FLANGE,5X24

92153-Y021

$1.90

92200

WASHER,12MM

92200-Y011

$3.86

92210

NUT,10MM

92210-Y010

$3.23

Kawasaki KFX®50 Front Hub Diagram

CAP,WHEEL

VALVE,RIM

ARM,BRAKE,RH

ARM,BRAKE,LH

TIRE

RIM,SILVER

PANEL-ASSY-BRAKE,FR,RH,SILVER

PANEL-ASSY-BRAKE,FR,LH,SILVER

HUB-ASSY,FR,SILVER

SHOE-ASSY-BRAKE,FR

CAM-BRAKE

BEARING-BALL,6002

BEARING-BALL,6003

SEAL,22X35X7

SPRING,BRAKE SHOE

SPRING,RETURN

COLLAR

COLLAR

BOLT,STUD,10X17

BOLT,FLANGE,5X24

WASHER,12MM

NUT,10MM
