Kawasaki KFX®50 Chassis Electrical Equipment Diagram

Description

Price

11065

CAP

11065-Y001

$11.35

21066

REGULATOR-VOLTAGE

21066-Y001

$50.27

21119

IGNITER

21119-Y001

$187.22

21121

COIL-IGNITION

21121-Y001

$34.26

26006

FUSE,7A

26006-Y001

$4.36

26031

HARNESS,MAIN

26031-Y001

$138.15

26031A

HARNESS,SUB

26031-Y003

Unavailable

27002

RELAY-ASSY

27002-Y001

$38.28

27005

SWITCH-ASSY-IGNITION

27005-Y001

Unavailable

28012

RESISTOR

28012-Y001

$28.86

92072

BAND

92072-Y003

$1.90

92153

BOLT,FLANGE,5X22

92153-Y006

$0.79

92210

NUT,6MM

92210-Y027

$0.79
