- JET SKI® ULTRA® 160LX
Fuel Injection
Kawasaki JET SKI® ULTRA® 160LX Fuel Injection Diagram
#
Description
Price
11056
BRACKET,SWITCH
11056-3855
$20.39
11057
BRACKET,REGULATOR&VDS
11057-7354
$24.51
11058
BRACKET,RELAY
11058-0929
$23.40
13280
HOLDER
13280-0789
$1.70
13280A
HOLDER,HARNESS
13280-3760
$3.70
14090
COVER,COUPLER
14090-1611
$8.51
21066
REGULATOR-VOLTAGE
21066-0755
$166.56
21175
CONTROL UNIT-ELECTRONIC
21175-2155
$876.81
21175A
CONTROL UNIT-ELECTRONIC
21175-2174
$876.81
21176
SENSOR,TEMP
21176-0741
$94.25
26004
FUSE-ASSY,20A
26004-0033
$2.92
26004A
FUSE-ASSY,10A
26004-0034
$2.67
26004B
FUSE-ASSY,15A
26004-0037
$2.77
26031
HARNESS,MAIN
26031-3957
$695.99
27002
RELAY-ASSY
27002-3703
$51.63
27010
SWITCH
27010-0710
$156.25
27010A
SWITCH,VDS
27010-3785
$259.40
92002
BOLT,6X12
92002-3763
$4.69
92022
WASHER,6.5X20X1.5
92022-3710
$3.65
92037
CLAMP,L=100
92037-3736
$5.52
92039
RIVET
92039-3714
$0.95
92072
BAND,OS170-FT7(BLACK)
92072-1414
Unavailable
92072A
BAND,L=372.24
92072-3883
$1.59
92150
BOLT,6X18
92150-3729
$4.69
92161
DAMPER,SWITCH
92161-1625
$6.75
92173
CLAMP
92173-0742
$9.17
92210
NUT,6MM
92210-3768
$5.79
110
BOLT,6X8
110R0608
$2.63
156
BOLT-WP,6X18
156R0618
$3.73
156A
BOLT-WP,6X20
156R0620
$3.65
220
SCREW-PAN-CROS,4X20
220R0420
$2.41
