Kawasaki JET SKI® SX-R™ 160 Fuel Injection Diagram

#

Description
Price

11057

BRACKET

11057-0451

$61.00

11057A

BRACKET,ELECTRIC CASE

11057-0452

$28.92

11061

GASKET

11061-1528

$13.41

13280

HOLDER,HARNESS

13280-3760

$3.70

21066

REGULATOR-VOLTAGE

21066-0755

$166.56

21175

CONTROL UNIT-ELECTRONIC

21175-1223

$752.02

21176

SENSOR,TEMP

21176-0741

$94.25

26006

FUSE,MINI BLADE,20A,YELLOW

26006-3704

$5.24

26031

HARNESS,MAIN

26031-2572

$506.44

27002

RELAY-ASSY

27002-3703

$51.63

27010

SWITCH,MAGNETIC

27010-0860

$164.03

27010A

SWITCH,VDS

27010-3785

$259.40

53044

TRIM

53044-0621

$1.28

59416

CASE-ELECTRIC

59416-3765

$65.38

59416A

CASE-ELECTRIC

59416-3766

$66.70

92002

BOLT,6X25

92002-3714

$5.00

92002A

BOLT,6X16

92002-3728

$4.69

92002B

BOLT,6X12

92002-3763

$4.69

92022

WASHER

92022-3035

$3.52

92026

SPACER

92026-3703

$4.69

92037

CLAMP,L=100

92037-3736

$5.52

92043

PIN

92043-3715

$7.34

92071

GROMMET

92071-3004

$3.99

92071A

GROMMET

92071-3837

$3.23

92072

BAND,L=188.85

92072-0105

$1.73

92072A

BAND,L=372.24

92072-3883

$1.59

92150

BOLT,6X80

92150-3711

$13.04

92150A

BOLT,6X18

92150-3729

$4.69

92151

BOLT,6X14

92151-3788

$2.34

156

BOLT-WP,6X20

156R0620

$3.65

220

SCREW-PAN-CROS,4X20

220R0420

$2.41

311

NUT-HEX,6MM

311R0600

$0.70

410

WASHER-PLAIN-SMALL,10MM

410AA1000

$0.59

410A

WASHER-PLAIN-SMALL,6MM

410S0600

$0.78
