2020 Kawasaki JET SKI® STX®160 Fuel Injection Diagram

← All diagrams

Find the part on the Fuel Injection diagram for your 2020 Kawasaki JET SKI® STX®160, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2020 Kawasaki JET SKI® STX®160 Fuel Injection Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11057

BRACKET,ELECTRIC CASE

11057-0452

1
Out of stock

11057A

BRACKET,ECU&RELAY

11057-2560

1
Out of stock

11060

GASKET

11060-3709

1
Out of stock

156

BOLT-WP,6X14

156R0614

1
Out of stock

156A

BOLT-WP,6X16

156R0616

1
Out of stock

156B

BOLT-WP,6X18

156R0618

1
Out of stock

156C

BOLT-WP,6X20

156R0620

1
Out of stock

21066

REGULATOR-VOLTAGE

21066-0755

1
Out of stock

21175

CONTROL UNIT-ELECTRONIC

21175-1530

1
Out of stock

21176

SENSOR,TEMP

21176-0741

1
Out of stock

220

SCREW-PAN-CROS,4X20

220R0420

1
Out of stock

26006

FUSE,MINI BLADE,20A,YELLOW

26006-3704

1
Out of stock

26031

HARNESS,MAIN

26031-2609

1
Out of stock

27002

RELAY-ASSY

27002-3703

1
Out of stock

27010

SWITCH,MAGNETIC

27010-0860

1
Out of stock

27010A

SWITCH,VDS

27010-3785

1
Out of stock

311

NUT-HEX,6MM

311R0600

1
Out of stock

410

WASHER-PLAIN-SMALL,10MM

410AA1000

1
Out of stock

410A

WASHER-PLAIN-SMALL,6MM

410S0600

1
Out of stock

59416

CASE-ELECTRIC

59416-3765

1
Out of stock

59416A

CASE-ELECTRIC

59416-3766

1
Out of stock

92002

BOLT,6X12

92002-3763

1
Out of stock

92022

WASHER

92022-3035

1
Out of stock

92022A

WASHER,6.5X20X1.5

92022-3710

1
Out of stock

92026

SPACER

92026-3703

1
Out of stock

92037

CLAMP,L=100

92037-3736

1
Out of stock

92043

PIN

92043-3715

1
Out of stock

92071

GROMMET

92071-3004

1
Out of stock

92071A

GROMMET

92071-3837

1
Out of stock

92072

BAND,L=188.85

92072-0105

1
Out of stock

92072A

BAND,L=372.24

92072-3883

1
Out of stock

92150

BOLT,6X80

92150-3711

1
Out of stock

92173

CLAMP

92173-0742

1
Out of stock

92173A

CLAMP

92173-1578

1
Out of stock
