1982 Yamaha IT465 (IT465J) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 1982 Yamaha IT465 (IT465J), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1982 Yamaha IT465 (IT465J) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

AXLE, KICK

56A-15661-01-00

1
Out of stock

2

GEAR, KICK

3R4-15641-00-00

1
Out of stock

3

CLIP 315156870000

90468-26048-00

1
Out of stock

4

WASHER, PLATE

90201-20358-00

1
Out of stock

5

SPRING, TORSION (3R4)

90508-30422-00

1

$18.75

In stock

6

GUIDE, SPRING

3R4-15664-00-00

1
Out of stock

7

GEAR, KICK IDLE

3R4-15651-00-00

1
Out of stock

8

WASHER, PLATE (525)

90201-17545-00

1

$6.68

In stock

9

CIRCLIP(1EY)

99009-17400-00

1
Out of stock

10

OIL SEAL,SD-TYPE

93102-20309-00

1

$8.77

In stock

11

KICK CRANK ASSEMBLY

3R4-15620-00-00

1
Out of stock

12

. BOSS, KICK CRANK

3R4-15621-01-00

1
Out of stock

13

BALL (12R)

93507-32031-00

1
Out of stock

14

SPRING COMPRESSION278156220000

90501-12081-00

1
Out of stock

15

WASHER PLATE 278156130000

90201-15234-00

1

$6.78

In stock

16

CIRCLIP

99006-10600-00

—

$6.91

In stock

17

COVER, KICK LEVER

2K7-15618-00-00

1
Out of stock

18

NUT(1EE)

90179-12659-00

—

$5.37

In stock
