Can-Am Commander 1000R EFI - DPS - 6PRA - Tundra Green - 60" Width CALI, 2024 Electric - Main Harness - 710008815 Diagram

#

Description
Price

300

Main Wiring Harness

710008815

$788.03

300a

Connector Guard

710007680

$8.43

4x4

Dielectric Grease

293550070

Unavailable

4x4

Housing

710002000

$6.73

4x4

Terminal

710003047

$3.12

4x4

Female Terminal

710005491

$1.57

BAT1

Heat Shrink

710002576

Unavailable

BAT1

Open Barell

710006004

Unavailable

BAT2

Heat Shrink

710002577

Unavailable

BAT2

TERMINAL_FEMALE - Call your local BRP dealership | STD Models

710000475

Unavailable

BN1

Heat Shrink

710002589

Unavailable

BN1

Open Barrel Terminal

278001392

$4.00

BP1

Shrink Tubing, 6 mm

515177246

$0.99

BP1

Open Barrel

278000992

$2.06

BP2

Heat Shrink

710002577

Unavailable

BP2

Open Barrel

710000530

Unavailable

BP2

Rubber Boot

278002266

Unavailable

CL

Female Housing 20 Circuits

278002858

$22.98

CL

Female Terminal

515178018

$0.90

CL

Female Terminal 22 AWG

515178349

$1.76

D2

Diode

409012700

$10.51

DC1

Dielectric Grease

293550070

Unavailable

DC1

Housing

710005373

$3.93

DC1

Female Terminal

710005952

$1.49

DC3

Female Housing, 2 Circuits

515175658

$14.90

DC3

Female Terminal

515175231

$4.00

DC3_CAP

Male Housing, 2 Circuits

710000667

$7.25

DESS.

Female Delphi Connector 5 Cavities

710007151

$15.64

DESS.

Lock

710007243

$3.93

DESS.

Wire Seal

710001163

$5.85

DESS.

Female Terminal

710001164

$6.79

DIFF

Label

710006076

Unavailable

DIFF

Dielectric Grease

293550070

Unavailable

DIFF

Housing Connector

710002003

$11.81

DIFF

Female Terminal

710005491

$1.57

DIFF

Terminal

710003047

$3.12

DLC

Female Housing 6 Circuits

710002706

$18.63

DLC

Lock

710002705

$4.15

DLC

Female Terminal

710005438

$3.88

DLC

Female Terminal

710005439

$4.15

DLC

FEMALE TERMINAL - Call your local BRP dealership

278001276

Unavailable

DPS

Dielectric Grease

293550070

Unavailable

DPS

Female Housing

710004989

$7.00

DPS

Lock | PACKARD 15430900

710005098

$1.57

DPS

Lock

710001222

$1.93

DPS

Plug

710002075

$2.84

DPS

Wire Seal

278002186

$5.18

DPS

Seal

710003153

$0.91

DPS

Female Terminal

278002187

$5.79

DPS

Terminal

710001873

$2.19

EVAP

Female Terminal Housing, 2 Circuits

409209200

Unavailable

EVAP

Wire Seal

710000402

$4.28

EVAP

Female Terminal

409012100

$4.28

FL-1

Fuse

710004226

Unavailable

FL-2

Fuse Link 41-50AMP

715002538

$20.12

FP

Male Housing, 4 Circuits

278002185

$6.73

FP

Lock

710001222

$1.93

FP

Lock

710006214

$0.73

FP

Wire Seal

278002186

$5.18

FP

Seal

710003153

$0.91

FP

Female Terminal

278002187

$5.79

FP

Terminal

710001873

$2.19

FRA

Female Housing, 2 Circuits

515175658

$14.90

FRA

Female Terminal

710003896

$1.70

FRONT_HL_M

Clip Bracket Connector (edge)

409210100

$1.94

FRONT_HL_M

Housing

515177201

$7.33

FRONT_HL_M

Lock

710006398

$0.73

FRONT_HL_M

Cap

710001225

$8.34

FRONT_HL_M

Seal Wire

710001332

$3.12

FRONT_HL_M

Seal

710001233

$2.93

FRONT_HL_M

Terminal

710001223

$2.93

FRONT_HL_M

Terminal

710001224

$2.93

FT

Clip

710000992

$3.88

FT

Female Housing, 2 Circuits

278000217

$8.72

FT

Wire Seal

278000218

$4.00

FT

Male Terminal

409004300

$5.30

HIBM

Label

710006074

Unavailable

HIBM

Dielectric Grease

293550070

Unavailable

HIBM

Housing

710002000

$6.73

HIBM

Terminal

710003047

$3.12

HIBM

Female Terminal

710005491

$1.57

HIC

Female Housing, 12 Circuits

710001930

$13.52

HIC

Lock

710006333

$5.52

HIC

Lock

710001222

$1.93

HIC

Cap

710001225

$8.34

HIC

Seal Wire

710001332

$3.12

HIC

Seal

710001233

$2.93

HIC

Terminal

710001229

$2.93

HIC

Terminal

710001228

$3.12

HIC_FD_F

Housing

710001132

$9.31

HIC_FD_F

Lock

710001133

$4.00

HIC_FD_F

Seal

278001482

$2.93

HIC_FD_F

Female Terminal

710001134

$5.85

HIC5M_L

Clip

710004988

Unavailable

HIC5M_L

Female Terminal Housing, 3 Circuits | XT Models

278000281

$9.31

HIC5M_L

Wire Seal

278001065

$5.85

HIC5M_L

Male Terminal | XT Models

278000222

$2.93

JB-1

Junction Block Cover

710006610

$19.37

JB-1

Junction Bloc

710006609

Unavailable

JB-1

Elastic Stop Nut M6, Brass

232561200

$4.03

KEYPAD

Housing

710001161

$10.51

KEYPAD

Lock

710001162

$3.18

KEYPAD

Wire Seal

710001163

$5.85

KEYPAD

Female Terminal

710001164

$6.79

PF1

Fuse Cover

278003553

$3.79

PF1

Fuse Base Ass'y

278003448

$30.57

PF1

Housing Support

710005671

Unavailable

PF1

Wire Seal

278000216

$2.93

PF1

Seal

293300198

$1.78

PF1

Wire Seal

278000218

$4.00

PF1

Wire Seal

710000048

$5.85

PF1

Wire Seal

278001065

$5.85

PF1

Female Terminal

515177177

$4.96

PF1

Female Terminal

710000918

$5.85

PF1

Female Terminal

278002578

$0.99

PF1_STD_LABEL

Fuses Decal

710008884

Unavailable

PF1-F11

Little Fuse, 20 Amperes

710000746

$7.78

PF1-F12

Little Fuse, 10 Amperes

710000744

$8.31

PF1-F14

Little Fuse, 10 Amperes

710000744

$8.31

PF1-F16

Little Fuse, 10 Amperes

710000744

$8.31

PF1-R3

Relay, 30 AMP

515176774

$18.63

PF1-R4

Relay

715900824

$18.63

PF1-R8

Relay

715900824

$18.63

PF1-R9

Relay, 30 AMP

515176774

$18.63

PF1-SP1

Little Fuse, 20 Amperes

710000746

$7.78

PF2

Fuse Cover

278003553

$3.79

PF2

Fuse Box Decal

710006792

$12.79

PF2

Fuse Base Ass'y

278003448

$30.57

PF2

Wire Seal

278000216

$2.93

PF2

Seal

293300198

$1.78

PF2

Wire Seal

278000218

$4.00

PF2

Wire Seal

278001065

$5.85

PF2

Female Terminal

710000918

$5.85

PF2

Female Terminal

278002578

$0.99

PF2_SP1

Little Fuse, 10 Amperes

710000744

$8.31

PF2_SP2

Little Fuse, 10 Amperes

710000744

$8.31

PF2_SP3

Little Fuse, 10 Amperes

710000744

$8.31

PF2-F18

Little Fuse, 10 Amperes

710000744

$8.31

PF2-F4

Little Fuse, 10 Amperes

710000744

$8.31

PF2-F5

Little Fuse, 10 Amperes

710000744

$8.31

PF2-F6

Little Fuse, 10 Amperes

710000744

$8.31

PF2-F7

Little Fuse, 10 Amperes

710000744

$8.31

PF2-F8

Little Fuse, 10 Amperes

710000744

$8.31

PF2-F9

Fuse, 25 Amps

710002590

$17.88

PF2-R1

Relay, 30 AMP

515176774

$18.63

PF2-R2

Relay

715900824

$18.63

PF3

Dielectric Grease

293550070

Unavailable

PF3

Fuse Holder

278001325

$8.31

PF3

Female Terminal

710000113

$5.85

PF3-F2

Fuse

710001613

$8.31

PF4

Dielectric Grease

293550070

Unavailable

PF4

Fuse Holder

278001325

$8.31

PF4

Female Terminal

710000113

$5.85

PF4

Female Terminal

710000357

$5.85

PF4-F21

Fuse, 30 Amperes

410917200

$3.12

POST-

Heat Shrink

710002576

Unavailable

POST-

Terminal

710000693

Unavailable

POST_ACC

Shrink Tubing, 6 mm

515177246

$0.99

POST_ACC

Open Barrel

278000992

$2.06

POST_FL

Shrink Tubing, 6 mm

515177246

$0.99

POST_FL

Open Barrel

278000992

$2.06

POST+

Heat Shrink

710002576

Unavailable

POST+

Terminal

710000693

Unavailable

PPS_F

Housing

710001232

$13.39

PPS_F

Lock

710001222

$1.93

PPS_F

Seal

710001233

$2.93

PPS_F

Terminal

710001229

$2.93

SB

Housing

710002177

$3.12

SB

Lock

710002043

$0.81

SB

Seal

278001482

$2.93

SB

Female Terminal

710001134

$5.85

SPLICE_ST

Adhesive Tape

710001767

Unavailable

SS

Female Housing, 2 Circuits

515177192

$7.25

SS

Lock

710001152

$4.00

SS

Wire Seal

710001163

$5.85

SS

Female Terminal

710001164

$6.79

STSW

Female Terminal Housing, 2 Circuits

409209200

Unavailable

STSW

Wire Seal

710000402

$4.28

STSW

Female Terminal

409012100

$4.28

XCU_A

Cover

515178602

$4.66

XCU_A

Housing 56 Circuits

515178618

Unavailable

XCU_A

Plate

515178604

$4.16

XCU_A

Plug

515178599

$2.99

XCU_A

Plate

515178603

$4.16

XCU_A

Terminal

515178596

$3.79

XCU_A

Terminal

515178598

$3.69

XCU_A

Terminal

515178666

$4.19
