Suzuki GV700GL (1985) RIGHT HANDLE SWITCH Diagram

#

Description

Price

1

GRIP, THROTTLE

57110-05A00

Unavailable

2

CAP

57216-05A00

Unavailable

3

LEVER, BRAKE This part replaces 57420-05A10.

57420-38B00

Unavailable

4

BOLT

57431-05A00

$8.17

5

.NUT This part replaces 08319-21065.

08319-2106B

$2.38

6

SWITCH ASSY, HANDLE, RH | Includes Item(s) 7 This part replaces 37200-05A60.

37200-05A62

Unavailable

7

SCREW This part replaces 02112-05205.

02112-0520B

$1.94

8

SWITCH ASSY, ST This part replaces 57460-49300.

57460-45500

$34.66

9

BAND

09407-12402

$2.82
