Suzuki GV1200GLF (1986) REAR WHEEL Diagram

#

Description
Price

1

HUB SET, REAR | Includes Item(s) 2

64100-05811

Unavailable

2

BUSHING

09319-12019

$13.11

3

SPACER

64730-05A00

Unavailable

4

BEARING This part replaces 08123-63037.

08123-6303B

$15.56

5

BEARING, LH

08143-63037

$22.58

6

DISC, REAR BRAKE (SILVER) | MODEL F

69210-05A01

Unavailable

6

(CA)DISC, REAR BRAKE (BLACK) | MODEL F2 CALIFORNIA ONLY

69210-05A50

Unavailable

6

DISC, REAR BRAKE (BLACK) | MODEL G

69210-05A60

Unavailable

7

BOLT (8X33) This part replaces 09106-08041.

09106-08148

$4.80

8

JOINT

64680-45113

$275.40

9

O RING

09280-65003

$3.72

10

WASHER

64677-45110

$2.92

11

BOLT

09119-06049

$1.56

12

WASHER

09169-06030

$3.15

13

AXLE, REAR

64711-05A02

Unavailable

14

WASHER

09160-16025

Unavailable

15

NUT

09141-16001

Unavailable

16

PIN, REAR AXLE This part replaces 04111-40308.

04111-4030A

$1.49

17

WASHER, RH

64743-05A00

Unavailable

18

SPACER, RH

64740-05A04

Unavailable

19

SPACER, LH This part replaces 64772-34200.

64772-34201

$23.07

20

BRACKET, CALIPER

69721-05A00

Unavailable

21

RIM, WHEEL (3.00X16 GOLD) | MODEL F This part replaces 65311-05A00.

65311-05A01

Unavailable

21

RIM, WHEEL (3.00X16 GOLD) | MODEL F2/G

65311-05A01

Unavailable

22

NO DESCRIPTION AVAILABLE | MODEL F This part replaces 65320-05A02.

65320-05A04

Unavailable

22

NO DESCRIPTION AVAILABLE | MODEL F2/G This part replaces 65320-05A03.

65320-05A04

Unavailable

23

TIRE, REAR (140/80-16 68H) | BS

65100-05A30

Unavailable

24

TUBE, INNER

65200-05A30

Unavailable

25

PROTECTOR This part replaces 65261-37330.

65261-37320

Unavailable

26

NO DESCRIPTION AVAILABLE This part replaces 94140-15501-KEY.

94100-27821

Unavailable

27

BAG

94141-31301

Unavailable

28

WHEEL WEIGHT | MODEL F/F2 This part replaces 55411-05A00.

43221-59J10

Unavailable

28

WHEEL WEIGHT | MODEL F/F2 This part replaces 55412-05A00.

43221-59J10

Unavailable

28

WHEEL WEIGHT | MODEL F/F2 This part replaces 55413-05A00.

43221-59J10

Unavailable

29

BALANCER, WHEEL (20G) This part replaces 55412-38A00.

55412-41F00

$8.12

29

BALANCER WHEEL (30G) This part replaces 55413-38A00.

55413-41F00

$7.50
