Suzuki GV1200GLF (1986) REAR SWINGING ARM Diagram

#

Description
Price

1

SWINGING ARM, REAR (BLACK) | Includes Item(s) 2

61100-05810-019

Unavailable

2

BEARING

09265-17012

$69.07

3

BOLT, PIVOT RH This part replaces 61213-05A00.

61213-24A00

Unavailable

4

NUT

09140-24007

$3.89

5

CAP

61222-05A01

$14.52

6

BOOT

61372-05A01

Unavailable

7

SCREW This part replaces 03211-04255.

03211-0425B

$2.70

8

SPRING,PROPELLE This part replaces 61373-34300.

61373-3430V

Unavailable

9

CLAMP This part replaces 09402-00304.

09402-00303

$5.76

10

HEAT GUARD

61285-05A00

Unavailable

11

BOLT This part replaces 01107-06106.

01500-0610B

$1.81

12

LOCK WASHER This part replaces 08321-21066.

08321-0106A

$1.84

13

BOLT This part replaces 01517-08254.

01550-0825A

$2.32

14

TROQUE LINK, REAR (BLACK)

64310-05A00-019

Unavailable

15

BOLT,10X39 This part replaces 09111-10011.

09111-10022-XC0

Unavailable

16

BOLT, REAR

09101-10017

Unavailable

17

WASHER, KNUCKLE END This part replaces 08322-11104.

08322-0110A

$1.84

18

NUT This part replaces 08314-41108.

08314-4010B

$2.50

19

COTTER PIN This part replaces 04111-20208.

04111-2020A

$1.49
