Suzuki GV1200GLF (1986) FRONT BRAKE HOSE Diagram

#

Description
Price

1

BOOT, MASTER CYLINDER This part replaces 59711-18400.

59711-49001

$7.51

2

BOLT

09360-10017

$3.42

3

WASHER (10X15X1.5)

09161-10009

$1.84

4

HOSE, FRONT BRAKE, NO.1

59480-05A01

Unavailable

5

ADAPTER

59290-43500

$36.17

6

JOINT

59490-05A00

Unavailable

7

BOLT, GEAR SHIFT LINK This part replaces 01107-06205.

01500-0620A

$1.78

8

LOCK WASHER This part replaces 08321-21064.

08321-0106A

$1.84

9

HOSE, FRONT BRAKE, NO.2

59240-05A01

Unavailable

10

GUIDE, HOSE, NO.1

59541-05A01

Unavailable

11

BOLT This part replaces 01107-06127.

01500-06127

$1.97

12

LOCK WASHER This part replaces 08321-21067.

08321-01067

$2.13

13

WASHER This part replaces 08322-21067.

08322-01067

$2.13

14

GUIDE, HOSE NO.2

59268-49001

Unavailable

15

BUSH

59244-49000

Unavailable
