Suzuki GV1200GLF (1986) CRANKCASE COVER Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE | Includes Item(s) 2 This part replaces 11340-05A02.

11340-05A04

Unavailable

2

LENS, OIL LEVEL

11971-33210

$18.20

3

GASKET,CL COVER This part replaces 11482-05A01.

11482-05A01-H17

Unavailable

4

PIN

04211-09169

$1.71

5

BOLT This part replaces 01547-06304.

01547-06307

$2.03

6

BOLT

01547-06357

$2.03

7

BOLT

01547-06457

$2.32

8

PLUG, OIL FILLER

09259-20007

$7.53

9

O RING

09280-17003

$1.65

10

SWITCH ASSY,OIL PRESSURE This part replaces 37820-33200.

37820-33D11

$25.13

11

CAP, SWITCH

11384-05A00

Unavailable

12

SCREW (5X20)

09127-05010

Unavailable

13

COVER, GENERATOR

11350-05A02

Unavailable

14

GASKET,GEN COVE This part replaces 11483-05A00.

11483-05A01

Unavailable

15

PIN (11X20) This part replaces 09206-11005.

09206-11017

$6.30

16

BOLT

01547-06307

$2.03

17

BOLT

01547-06457

$2.32

18

COVER, SECONDARY DRIVE | MODEL F/F2

11361-05A02

Unavailable

19

BOLT

01547-06407

$2.32

20

BOLT | MODEL F/F2

01547-06457

$2.32

21

NO DESCRIPTION AVAILABLE | MODEL F/F2 This part replaces 11369-05A00.

11369-05A01

Unavailable

22

COVER, SECONDARY DRIVE | MODEL G

11361-05A10

Unavailable

23

WASHER | MODEL G This part replaces 09160-06097.

09160-06125

$1.91

24

CUSHION, OUTER | MODEL G

09161-09006

$2.36

25

SPACER | MODEL G

09180-06168

Unavailable

26

CUSHION, INNER | MODEL G

09161-09005

$2.36
