Suzuki GV1200GLF (1986) AIR CLEANER Diagram

#

Description
Price

1

CHAMBER ASSY | Includes Item(s) 2 - 8

13701-05A00

Unavailable

2

TUBE, OUTLET

13881-05A00

Unavailable

3

CLAMP This part replaces 09402-58207.

09402-58208

$5.36

4

HOSE, BREATHER

13850-05A00

Unavailable

5

CLIP This part replaces 13824-43400.

09401-14404

$2.28

6

CLIP This part replaces 13828-00020.

09401-14401

$2.53

7

TUBE, DRAIN

13870-05A00

Unavailable

8

CLAMP This part replaces 13825-43400.

09401-13417

$2.26

9

CASE ASSY, FILTER | Includes Item(s) 10 - 18

13702-05A00

Unavailable

10

FILTER ASSY This part replaces 13780-05A00.

13780-01D00

$39.78

11

SCREW This part replaces 02112-05125.

02112-0512A

$1.49

12

LOCK WASHER This part replaces 08321-21055.

08321-0105A

$1.84

13

CLAMP, CHAMBER

13826-05A00

Unavailable

14

JOINT, TUBE

13739-05A00

Unavailable

15

CLAMP, CASE

13827-05A00

Unavailable

16

CAP, DRAIN

13872-05A00

Unavailable

17

CLIP

09401-14301

$2.35

18

FILTER, DRAIN

13789-00020

Unavailable

19

BOLT, CANISTER This part replaces 01107-06168.

01500-06167

$1.97

20

WASHER This part replaces 08322-21068.

08322-01067

$2.13

21

CLAMP This part replaces 09407-11301.

09407-18302

$2.28

22

CLAMP This part replaces 09404-06412.

09404-06039

$1.74
