Sea-doo GTX RFI, 5566/5565, 2002 Oil Injection System Diagram

#

Description
Price

1

Oil Tank

275000238

$98.99

2

Oil Cap

275000186

Unavailable

3

O-RING - Call your local BRP dealership

293250025

Unavailable

4

FILLER NECK - Call your local BRP dealership

275000242

Unavailable

5

Gasket

293250132

Unavailable

6

Nut-Neck Oil Filler

211100013

Unavailable

7

OIL LEVER SENSOR ASS'Y - Call your local BRP dealership

278001401

Unavailable

7

Grommet

293720008

$14.75

8

Wire Seal

278000218

$4.49

9

Male Terminal | XT Models

278000222

$3.29

10

Female Housing, 2 Circuits

278000217

$9.79

11

Filler Hose

275000230

Unavailable

12

FITTING ELBOW 90 - Call your local BRP dealership

293710051

Unavailable

13

Was 275500008 Hose 12 mm

219704356

$21.99

14

Was 293550004 Dielectric Grease, 150 g

219704453

$38.99

15

Tie Wrap 94 mm | 4X4

293750001

$1.49

16

Tridon Clamp

293650035

$7.49

17

Tridon Gear Clamp

293650170

$2.00

18

Was 275500549 Hose 1/4"

219704357

$199.99

19

Check Valve

275500398

$11.49

20

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$33.99

21

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

22

Oetiker Clamp

293650042

$3.19

23

Grommet

293720008

$14.75

24

Oil Cap Chain

275500015

Unavailable

25

Pop Rivet 1/8"

390407900

$1.49

26

Tie Wrap 142 mm

293750002

$1.49

27

OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900.

779119

$12.99

2T Snowmobile Premium Mineral Oil This part replaces 413803000.

779120

$43.99

OIL 2T CARB PREM. MINERAL 55 GAL/205L This part replaces 413803200.

779123

Unavailable

SYNTHETIC INJECTION OIL, 12 X 1 LITER - Call your local BRP dealership

413710500

Unavailable

OIL 2T 3X1G SYNTH - Call your local BRP dealership This part replaces 293600046.

293600133

Unavailable

OIL 2T E-TEC SYNTHETIC 55 GAL/205L This part replaces 293600047.

779130

Unavailable

FORMULA XP-S DI OIL (12 X 1 LITERS) - Call your local BRP dealership

293600032

Unavailable

OIL 2T 3X1G SYNTH - Call your local BRP dealership This part replaces 293600046.

293600133

Unavailable

OIL 2T E-TEC SYNTHETIC 55 GAL/205L This part replaces 293600047.

779130

Unavailable

28

Tie-Rap 180 mm

414115200

$1.49

29

Norma Clamp

293650084

$4.19

30

Flat Washer M3, Stainless

234032600

$1.49

31

Tridon Gear Clamp

293650171

$3.19
