Sea-doo GTX LTD iS 260, 2013 Seat Suspension Diagram

#

Description
Price

1

Socket Head Screw M6 X 12, Scotch Grip

205561260

$1.54

2

Socket Head Screw M6 X 20, Scotch Grip

205562060

$0.62

3

Socket Head Screw M6 X 25, Scotch Grip

205562560

$1.70

4

Socket Head Screw M8 X 20, Scotch Grip

205582060

$4.28

5

Hex. Screw M6 X 70

207067060

$4.62

6

HEX. SCREW M8 X 60 - Call your local BRP dealership

207086060

$1.85

7

Hex. Screw M4 X 40

207144060

$4.28

8

HEX. SCREW M12 X 70, SCOTCH GRIP - Call your local BRP dealership

207227060

Unavailable

9

Hex. Screw M8 X 50, Scotch Grip

207285060

$1.70

10

HEX. SCREW M8 X 75, SCOTCH GRIP - Call your local BRP dealership

207287560

Unavailable

11

Hex. Screw M6 X 20, Scotch Grip

207362060

$1.22

12

Hex. Screw M8 X 30, Scotch Grip

207383060

$1.55

13

Flat Washer

211200051

$1.34

14

Hex. Screw M10 X 110, Scotch Grip

230201060

$10.54

15

Elastic Stop Nut M4

232541200

$1.74

16

Elastic Stop Nut M6, Brass

232561200

$3.51

17

Hex. Elastic Nut M8 Brass

232581200

$1.29

18

Flat Washer 10 mm, Stainless

234001600

$0.91

19

Flat Washer 4 mm, Stainless

234041600

$0.91

20

Stainless Flat Washer M6

234061600

$0.25

21

Flat Washer M8, Stainless

234080600

$1.25

22

Stainless, Flat Washer 8 mm

234081600

$0.46

23

Flat Washer 8 mm, Stainless

234082600

$1.98

24

Hex. Screw M8 X 30, Scotch Grip

250000526

$0.64

25

Flat Washer 8 mm, Stainless

250200175

$1.29

26

FLAT WASHER M12 - Call your local BRP dealership

250200053

Unavailable

27

Flat Washer M6

250200115

$2.72

28

Position Sensor

420866120

$77.97

29

CENTRAL BELLOWS - Call your local BRP dealership

279000008

Unavailable

30

Lateral Bellows

279000009

$63.02

31

Retaining Plate

279000010

$16.89

32

Retaining Ring

279000011

$13.62

33

Bushing

279000019

$19.47

34

Bushing

279000019

$19.47

35

PIVOT TUBE - Call your local BRP dealership

279000031

Unavailable

36

PIVOT TUBE - Call your local BRP dealership

279000033

Unavailable

37

FRONT ARM ASS'Y - Call your local BRP dealership | Includes 41 to 41d

279000308

Unavailable

38

PIVOT TUBE - Call your local BRP dealership

279000038

Unavailable

39

PIVOT TUBE - Call your local BRP dealership

279000041

Unavailable

40

RUBBER BUMPER - Call your local BRP dealership

279000047

Unavailable

42

Bushing

279000051

$79.97

45

SHOCK LOWER HOLDER - Call your local BRP dealership

279000055

Unavailable

46

Shock Upper Holder

279000057

$189.20

47

UPPER SPRING HOLDER - Call your local BRP dealership

279000061

Unavailable

48

FOOT REST - Call your local BRP dealership

279000306

Unavailable

49

LH SPRING HOLDER - Call your local BRP dealership

279000070

Unavailable

50

RH SPRING HOLDER - Call your local BRP dealership

279000074

Unavailable

51

REAR ARM MOULDING - Call your local BRP dealership

279000080

Unavailable

52

LH REAR BASE - Call your local BRP dealership

279000083

Unavailable

52

RH REAR BASE - Call your local BRP dealership

279000087

Unavailable

54

LH CLAMP - Call your local BRP dealership

279000089

Unavailable

54

RH CLAMP - Call your local BRP dealership

279000092

Unavailable

56

Retaining Ring

279000115

$12.68

57

POSITION SENSOR BRACKET - Call your local BRP dealership

279000098

Unavailable

58

SENSOR LEVER - Call your local BRP dealership

279000099

Unavailable

59

RETAINING RING - Call your local BRP dealership

279000100

Unavailable

60

RETAINING PLATE - Call your local BRP dealership

279000114

$13.83

64

CLAMP - Call your local BRP dealership

279000106

Unavailable

65

POSITION SENSOR COVER - Call your local BRP dealership

279000107

$7.02

66

O-Ring

279000108

$4.89

67

Lower Spring Protector

279000121

$16.89

68

REAR ARM ASS'Y - Call your local BRP dealership | Includes 1001 to 1001c

279000001

Unavailable

69

SPRING ALIGNMENT ADAPTOR - Call your local BRP dealership

279000154

Unavailable

70

SPRING ALIGNMENT ARM - Call your local BRP dealership

279000157

Unavailable

73

PAINTED SPRING - Call your local BRP dealership

279000128

Unavailable

74

Spring Spacer

279000130

$18.43

75

PAINTED SPRING - Call your local BRP dealership

279000131

Unavailable

76

UPPER SPRING PROTECTOR - Call your local BRP dealership

279000134

Unavailable

77

BUSHING - Call your local BRP dealership

279000137

$7.32

78

SPACER - Call your local BRP dealership

279000138

Unavailable

79

THREADED ROD - Call your local BRP dealership

279000139

Unavailable

80

BRACKET - Call your local BRP dealership

279000155

Unavailable

81

SPACER - Call your local BRP dealership

279000153

Unavailable

82

Tubing 6 Mm 3000Mm Long

219704425

$13.14

83

Flat Washer

279000336

$8.35

84

FRONT ARM BASE - Call your local BRP dealership

279000167

Unavailable

92

Hook | Package LTD

291002351

$69.97

93

Black, Finition Plate

291001386

$8.57

94

U-Clamp

292000933

$32.47

95

Pop Rivet 3/16"

293150005

$0.40

96

Pop Rivet 3/16"

293150123

$3.43

97

Pop Rivet 3/16"

293150176

$1.82

98

Norma Clamp

293650079

$8.89

99

Oetiker Gear Clamp

293650199

$7.16

100

Mount Dart

293730040

$0.86

101

Tie Wrap 94 mm | 4X4

293750001

$0.83

102

Tie Wrap 368 mm

293750008

$0.85

103

Tie-Rap 180 mm

414115200

$0.09

104

Retaining Cable

708200118

Unavailable

200

ACTUATOR - Call your local BRP dealership

279000117

Unavailable

201

CONNECTOR HOSE - Call your local BRP dealership

279000162

Unavailable

202

PUMP ASS'Y - Call your local BRP dealership This part replaces 279000207.

279000208

Unavailable

203

FRONT ARM ASS'Y - Call your local BRP dealership | Includes 41 to 41d

279000308

Unavailable

204

Shock

279000247

$1,071.51
