Sea-doo GTX Limited, 5837/5842, 1998 Oil Injection System Diagram

#

Description
Price

1

Oil Tank

275000238

$76.67

2

Elbow Fitting 90°

293710070

Unavailable

3

Grommet

293720008

$10.91

4

Oil Cap

275000186

Unavailable

5

O-RING - Call your local BRP dealership

293250025

Unavailable

6

Tie Wrap 94 mm | 4X4

293750001

$0.83

7

Filler Neck

275000212

Unavailable

8

Pop RIvet 1/8 X ,375

293150285

$0.23

9

Oil Cap Chain

275500015

Unavailable

10

Gasket

293250016

Unavailable

11

Nut-Neck Oil Filler

211100013

Unavailable

12

Filler Hose

275000185

Unavailable

13

Tridon Clamp

293650035

$5.80

14

Flat Washer M3, Stainless

234032600

$0.52

15

Oetiker Clamp

293650042

$1.40

16

HOSE-6MM. 5000MM LONG - Call your local BRP dealership

219704396

Unavailable

17

Tie Wrap 142 mm

293750002

$0.88

18

Check Valve

275500398

$8.57

19

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$27.27

20

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

21

Oil Level Sensor Ass'y | Includes 21 - 24.

278001315

Unavailable

22

Female Housing, 2 Circuits

278000217

$7.59

23

Wire Seal

278000218

$3.48

24

Male Terminal | XT Models

278000222

$2.55

25

Grommet

204470104

Unavailable

26

OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900.

779119

$10.74

2T Snowmobile Premium Mineral Oil This part replaces 413803000.

779120

Unavailable

OIL 2T CARB PREM. MINERAL 55 GAL/205L This part replaces 413803200.

779123

Unavailable

SYNTHETIC INJECTION OIL, 12 X 1 LITER - Call your local BRP dealership

413710500

Unavailable

OIL 2T 3X1G SYNTH - Call your local BRP dealership This part replaces 293600046.

293600133

Unavailable

OIL 2T E-TEC SYNTHETIC 55 GAL/205L This part replaces 293600047.

779130

Unavailable

27

Was 293550004 Dielectric Grease, 150 g

219704453

$36.54
