Sea-doo GTX 4-TEC, 5573/5574/5593/5594, 2002 Oil Separator Diagram

#

Description
Price

1

Oil Pump Housing

290811840

Unavailable

2

Pump Shaft Ass'y

290837542

Unavailable

3

Oil Pump Rotor 16 mm

420956675

$37.99

4

Oil Pump Cover

420811851

$34.99

5

Torx Flange Screw M6 X 16

420641048

$2.99

6

Gasket

420950970

$12.99

7

Torx Flange Screw M6 X 25

420641238

$3.39

8

Oil Sieve Cover

290811891

Unavailable

9

Seal Ring

290630240

Unavailable

10

GASKET - Call your local BRP dealership

290950850

Unavailable

11

OIL SIEVE - Call your local BRP dealership

420256570

Unavailable

12

Torx Flange Screw M6 X 85

420641228

$7.59

13

Torx Flange Screw M6 X 25

420641238

$3.39

14

Torx Flange Screw M6 X 25

420641238

$3.39

15

Gasket

290630231

Unavailable

16

Oil Separator Housing

290956761

Unavailable

17

Interr.Pression*Oil Tk Pres Sw This part replaces 420256885.

420256886

$52.99

18

Oil Separator Cover

290811962

Unavailable

19

SOLENOID SHUT-OFF - Call your local BRP dealership

420956661

Unavailable

20

Gasket

290630540

Unavailable

21

Compression Spring

290939250

Unavailable

22

Valve Disc

290856055

Unavailable

23

Retaining Ring

290845620

Unavailable

24

Torx Flange Screw M6 X 16

420641048

$2.99

25

Gasket

290630220

Unavailable

26

Torx Flange Screw M6 X 25

420641238

$3.39

27

Plug Cover, Yellow

420956923

$24.49

28

Rubber Bracket

420660090

$4.19

29

Spacer

290847970

Unavailable

30

Flat Washer M6

420827968

$1.99

31

Torx Flange Screw M6 X 35

420641258

$3.49

32

Front Transport Bracket

290851610

Unavailable

33

Torx Flange Screw M6 X 16

420641048

$2.99

34

Formed Hose

290956970

Unavailable

35

Gear Clamp

420851673

$5.79

Oeticker Gear Clamp, 25.6-706R

509000442

$5.29

Loctite 243, 10 ml

293800060

$21.49

Not Available As Spare Part - Friction Washer

Unavailable
