Yamaha GTS1000AFC (GTS1000A CA) 1994 STEERING 2 Diagram
#
1
FRT LWR ARM CMPL L
4BH-23570-02-P1
Unavailable
2
BALL JOINT 2
4BH-23579-00-00
Unavailable
3
WASHER, FELT
4BH-23165-00-00
Unavailable
7
BEARING, STEERING UPPER
4BH-23873-00-00
Unavailable
8
PLANE BEARING, STEERING LOWER
4BH-23875-00-00
Unavailable
9
COVER, LOWER 1
4BH-23123-00-00
Unavailable
10
BOLT, UPPER
4BH-23366-00-00
Unavailable
11
WASHER, PLATE
90201-182R4-00
Unavailable
14
CAP, SIDE 1
4BH-23338-00-00
Unavailable
15
BOLT, LOWER
4BH-23367-00-00
Unavailable
16
WASHER, PLATE
90201-177M0-00
Unavailable
17
NUT, CASTLE
95307-16900-00
Unavailable
18
PIN, COTTER (AM5)
91490-30045-00
Unavailable
19
CAP, SIDE 2
4BH-23339-00-00
Unavailable
20
PAD, STEERING
4BH-23815-00-00
Unavailable
21
COVER, OUTER 2
4BH-23132-00-00
Unavailable
22
SCREW, ROUND HEAD(55K)
90150-06021-00
Unavailable
23
COVER, LOWER 2
4BH-23133-00-00
Unavailable
24
SCREW, BINDING
90154-05071-00
Unavailable
25
NUT(1KT)
90179-05523-00
Unavailable
26
SHOCK ABSORBER ASY
4BH-23350-01-93
Unavailable
27
BOLT 1
4BH-23346-00-00
Unavailable
28
COLLAR
4BH-23113-00-00
Unavailable
29
O-RING (601)
93210-20027-00
Unavailable
30
WASHER, PLATE(48H)
90201-161J3-00
Unavailable
31
NUT, U
95611-16100-00
Unavailable
32
HOLDER, SUB-TANK 2
4BH-22276-00-00
Unavailable
33
DAMPER, SUB TANK
4BH-22261-01-00
Unavailable
34
MOLD, SIDE COVER 1
1UF-2171L-01-00
Unavailable
35
BOLT, FLANGE
95817-06016-00
Unavailable
36
BAND (MADE IN CANADA)
90460-50079-00
Unavailable
37
CLAMP(2TV)
90464-10112-00
Unavailable
38
BOLT
90109-106F7-00
Unavailable
39
COLLAR (23X)
90387-126H8-00
Unavailable
40
WASHER, PLATE(3BM)
90201-105R9-00
Unavailable
41
NUT, U
95614-10100-00
Unavailable
42
DAMPER
22F-2139X-00-00
Unavailable
