Description

Price

1

Hex. Screw M8 X 40

207184060

$2.22

2

Hex. Screw M10 X 20, Scotch Grip

207302060

$4.02

3

Hex. Screw M6 X 12, Scotch Grip

207361260

$0.58

4

Elastic Stop Nut M6, Brass

232561200

$4.23

5

Flat Washer 10 mm, Stainless

234000600

$1.46

6

Stainless Flat Washer M6

234061600

$0.33

7

Flat Washer 8 mm, Stainless

234082600

$2.43

8

Torx Screw Plastite M6

250000466

$6.98

9

Strap

269502417

$17.69

10

Throttle Position Sensor

278002283

$119.99

11

LH Throttle Sensor

278002284

$119.99

12

Switch RH Mode/Set

278002602

$126.99

13

Switch LH VTS/Sport/Eco | Package STD

278002767

$126.99

15

Safety Nut (DESS Switch)

278002963

$3.28

16

O.T.A.S Actuator

278003537

$42.99

17

Safety Lanyard Ass'y, RFID | Includes 8020 to 8020j

278003402

$84.99

18

Batt. Support | Except Engine 900HO ACE

278003136

$28.99

19

Battery Ground Cable

278003270

$41.49

21

Main Harness

278003336

$669.99

22

Clip

278003521

$17.62

23

Tie Wrap 368 mm

293750008

$1.04

24

Starter Relay

278003012

$42.49

25

Diagnostic Connector

278002704

$19.49

26

Tie-Rap 180 mm

414115200

$0.11

27

Battery Ass'y, 18 Amperes | XT Models, Includes 72 To 73

410301203

$154.99

27a

Battery Bolt Kit

250000282

$7.29

28

Cable-Starter

278003370

$39.99

29

LCD Gauge | Model GTI LTD 155

278003378

$1.00

30

Steering Harness Ass'y | GTI LTD, WAKE

278003262

$349.99

31

Terminal Dess One-Wire | Except Model Europe

515178840

$83.49

32

Voltage Regulator | For replacement, refer to service bulletin 2005-5

710001103

$142.99

33

O.T.A.S. Sensor Ass'y

278003009

$109.99

34

O.T.A.S. Sensor

278003008
