Sea-doo GTI, 5641, 1997 Oil Injection System (GTI) Diagram

#

Description
Price

1

Oil Tank

275000238

$88.03

2

Oil Tank Cap

275000199

Unavailable

3

O-RING - Call your local BRP dealership

293250025

Unavailable

4

Filler Neck | GTI 5641.

275000064

Unavailable

5

Gasket

293250016

Unavailable

6

Nut-Neck Oil Filler

211100013

Unavailable

7

Oil Level Sensor

278000478

Unavailable

8

Wire Seal

278000218

$4.00

9

Male Terminal | XT Models

278000222

$2.93

10

Female Housing, 2 Circuits

278000217

$8.72

11

Filler Hose

275000185

Unavailable

12

FITTING ELBOW 90 - Call your local BRP dealership

293710051

Unavailable

13

Was 275500008 Hose 12 mm

219704356

$6.82

14

Tie-Rap 180 mm

414115200

$0.10

15

Tie Wrap 94 mm | 4X4

293750001

$0.96

16

Tridon Clamp

293650035

$6.66

17

Tridon Gear Clamp

293650170

$2.00

18

Was 415110000 Polyurethane Hose 5.2 mm

219704414

$114.15

19

Check Valve This part replaces 275500087.

275501246

Unavailable

20

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$31.31

21

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

22

Oetiker Clamp

293650042

$1.61

23

Grommet

293720008

$12.52

24

Grommet

204470104

Unavailable

25

Oil Cap Chain

275500015

Unavailable

26

Pop Rivet 1/8”

293150015

$0.33

27

Flat Washer M3, Stainless

234032600

$0.52
