Sea-doo GTI , 2015 Oil Separator _15R1528 Diagram

#

Description

Price

1

Oil Pump Housing

420812723

$105.19

2

Oil Pump Shaft

420837543

$56.69

3

Oil Pump Rotor 16 mm

420956675

$33.55

4

Oil Pump Cover

420811851

$31.31

5

Torx Flange Screw M6 X 16

420641048

$2.82

6

Oil Sieve

420856520

$24.60

7

Oil Suction Pump Gasket | Included in gasket kit

420631486

$9.03

8

Torx Flange Screw M6 X 25

420641238

$3.07

9

OIL FILLER TUBE ASS'Y - Call your local BRP dealership | Includes 9 to 10

420856511

$34.30

10

Gasket

420430240

$4.15

11

Torx Flange Screw M6 X 45

420641198

$3.88

12

Plug Cover, Yellow

420956923

$22.36

13

Retaining Band

420660620

$7.01
