Sea-doo GTI 130 Rental, 2009 Electrical System STD RENTAL Diagram

#

Description
Price

1

MODULE SUPPORT - Call your local BRP dealership

278002699

Unavailable

2

Pop Rivet 3/16"

293150123

$4.39

3

Hex. Screw 10-14 X 7/8”

211000023

$3.69

4

Flat Washer M6, Stainless

234062600

$1.49

5

Interrupter T.O.P.S.

278001992

$75.99

6

Voltage Regulator | For replacement, refer to service bulletin 2005-5

710001103

$139.99

7

TORX SCREW 10-14 X 1-1/8 - Call your local BRP dealership

250000236

Unavailable

8

Flat Washer M6, Stainless

234062600

$1.49

9

Starter Relay

278003012

$43.99

10

Diagnostic Connector

278002704

$19.49

11

Battery | Includes 900 to 900a

515176151

$209.95

12

Battery Bolt Kit

515176081

$7.19

13

BUSHING - Call your local BRP dealership

278002304

Unavailable

14

LOWER BATTERY PAD - Call your local BRP dealership

278001582

Unavailable

15

BATTERY SUPPORT - Call your local BRP dealership

278001677

Unavailable

16

Hex. Screw M8 X 40, Scotch Grip

207284060

$2.24

17

Flat Washer 8 mm, Stainless

234082600

$2.49

18

BATTERY SUPPORT - Call your local BRP dealership

278001966

Unavailable

19

BATTERY STRAP 337 MM - Call your local BRP dealership

278001764

Unavailable

20

Elastic Stop Nut M6, Brass

232561200

$4.19

21

Tie-Rap 180 mm

414115200

$1.49

22

Tie Wrap 368 mm

293750008

$1.49

23

GROUND CABLE ASS'Y - Call your local BRP dealership

278002177

Unavailable

24

Hex. Screw M10 X 20, Scotch Grip

207302060

$4.09

25

Flat Washer 10 mm, Stainless

234000600

$1.49

26

STARTER CABLE - Call your local BRP dealership

278002267

Unavailable

27

Elastic Stop Nut M6, Brass

232561200

$4.19

28

Stainless Flat Washer M6

234061600

$1.49

29

Was 293550004 Dielectric Grease, 150 g

219704453

$38.99

30

Female Terminal Housing, 3 Circuits | XT Models

278000281

$9.99

31

Wire Seal

278000216

$3.29

32

Hex. Screw M6 X 12, Scotch Grip

207361260

$1.49

33

Stainless Flat Washer M6

234061600

$1.49

34

RETAINER - Call your local BRP dealership

275500553

Unavailable

35

Hex. Flange Screw K40 X 16

241141660

$1.49

36

Digital Multifunction Gauge | Includes 39 to 40

278002273

$1,259.99

37

Check Valve

275500398

$11.49

38

Tie Wrap 142 mm

293750002

$1.49

39

Gauge Bezel, Black

278002135

$28.99

40

Hex. Flange Screw K40 X 25

241142560

$2.69

41

TRIM - Call your local BRP dealership

293830113

Unavailable

42

Safety Nut (DESS Switch)

278002963

$3.39

43

SAFETY LANYARD, RENTAL - Call your local BRP dealership

278002210

Unavailable

44

SAFETY LANYARD, LEARNING KEY - Call your local BRP dealership

278002406

Unavailable
