Suzuki GT380 (1977) AIR CLEANER (GT380L Diagram

#

Description
Price

1

CLEANER ASSY, AIR | L,M,A; TO 13700-33112

13700-33110

Unavailable

1

CLEANER ASSY, AIR | B; Includes Item(s) 2 - 12

13700-33112

Unavailable

2

FILTER, AIR CLEANER | L,M,A,B

13780-33110

Unavailable

3

FILTER, AIR CLEANER | L,M,A,B; FROM 13781-33110 This part replaces 13781-33111.

13780-33110

Unavailable

4

SCREW | L,M,A,B This part replaces 02112-06258.

02112-06257

$1.78

5

LOCK WASHER | L,M,A,B This part replaces 08321-21068.

08321-01067

$2.13

6

PIPE, INLET | L,M,A,B

13722-33110

Unavailable

7

GASKET, BOLT | L,M,A,B

13742-05110

Unavailable

8

BOLT | L,M,A,B

13726-33110

Unavailable

9

WASHER | L,M,A,B This part replaces 08322-21058.

08322-01057

$2.13

10

PLUG NUT | L,M,A

13751-33110

Unavailable

10

PLUG NUT | B

13751-36010

Unavailable

11

COVER, AIR CLEANER RH | L,M,A,B

13771-33110

Unavailable

12

COVER, AIR CLEANER LH | L,M,A,B

13772-33110

Unavailable

13

BOLT | L,M,A,B This part replaces 01112-06358.

64455-07L00

$1.59

14

WASHER (6.5X20X1.2) | L,M,A,B; 6.5x20x1.2 This part replaces 09160-06027.

09160-06077

$1.91

15

LOCK WASHER | L,M,B This part replaces 08321-21068.

08321-01067

$2.13

16

HOSE, AIR INLET | L,M; TO 13880-33101

13880-33100

Unavailable

16

HOSE, AIR INLET | A,B

13880-33101

Unavailable

17

CLAMP, (1) | L,M,A,B

09402-52306

$4.91

18

CLAMP, (2) | L,M,A,B

09402-79401

Unavailable

19

SCREW | L,M,A,B This part replaces 03211-04258.

03211-0425B

$2.70

20

PIPE,INTAKE | L,M,A,B This part replaces 13111-33100.

13111-33101

$17.68

21

CLAMP | L,M,A,B; FROM 09402-00228 This part replaces 09402-48303.

09402-48208

$4.64

22

SCREW | L,M,A,B This part replaces 02111-04208.

02112-0420A

$1.49
