FUEL TANK
Suzuki GT250 (1977) FUEL TANK Diagram
#
1
NO DESCRIPTION AVAILABLE | K; Includes Item(s) 2 - 3 This part replaces 44100-18830-157.
44110-18671-737
Unavailable
2
TAPE, STRIPING UPPER | K; TO 68100-18830-724
68116-18630-724
Unavailable
3
TAPE, STRIPING LOWER | K; TO 68100-18830-724
68115-18640-724
Unavailable
4
NO DESCRIPTION AVAILABLE | K; Includes Item(s) 5 - 6 This part replaces 44100-18830-215.
44110-18671-737
Unavailable
5
NO DESCRIPTION AVAILABLE | K; TO 68100-18830-718 This part replaces 68116-18630-718.
68100-18830-718
Unavailable
6
NO DESCRIPTION AVAILABLE | K; TO 68100-18830-718 This part replaces 68115-18640-718.
68100-18860-019
Unavailable
7
TANK, FUEL | L; TO 44110-18651-759 USED WITH 68111-34000 AND 09127-03002
44110-18650-759
Unavailable
7
NO DESCRIPTION AVAILABLE | L; TO 44110-18651-715 USED WITH 68111-34000 AND 09127-03002 This part replaces 44110-18650-715.
44110-18680-737
Unavailable
7
NO DESCRIPTION AVAILABLE | L; TO 44110-18651-279 USED WITH 68111-34000 AND 09127-03002; Includes Item(s) 8 - 9 This part replaces 44110-18650-279.
44110-18680-737
Unavailable
8
TAPE, STRIPING RH | L; TO 68100-18850-742
68115-18650-742
Unavailable
9
NO DESCRIPTION AVAILABLE | L; TO 68100-18850-742 This part replaces 68125-18650-742.
68100-18850-742
Unavailable
10
TANK, FUEL | M; TO 44110-18681-288 USED WITH 68111-31000 AND 09127-03002
44110-18660-288
Unavailable
10
TANK, FUEL | M; TO 44110-18662-288 USED WITH 44300-15650 (1PC), 09128-06006 (2PC), 09168-06010 (2P; Includes Item(s) 11 - 14
44110-18661-288
Unavailable
11
NO DESCRIPTION AVAILABLE | M; TO 68100-18860-019 This part replaces 68115-18660-019.
68100-18860-019
Unavailable
12
NO DESCRIPTION AVAILABLE | M; TO 68100-18860-019 This part replaces 68125-18660-019.
68100-18860-019
Unavailable
13
NO DESCRIPTION AVAILABLE | M; TO 68100-18860-019 This part replaces 68116-18660-019.
68100-18860-019
Unavailable
14
NO DESCRIPTION AVAILABLE | M; TO 68100-18860-019 This part replaces 68126-18660-019.
68100-18860-019
Unavailable
15
TANK, FUEL | A; TO 44110-18671-00T USED WITH 44300-15650(1PC), 09128-06006(2PC), 09168-06010(2PC),; Includes Item(s) 16 - 19
44110-18670-00T
Unavailable
16
NO DESCRIPTION AVAILABLE | A; TO 68100-18890-998 This part replaces 68115-18670-998.
68100-18890-998
Unavailable
17
NO DESCRIPTION AVAILABLE | A; TO 68100-18890-998 This part replaces 68125-18670-998.
68100-18890-998
Unavailable
18
NO DESCRIPTION AVAILABLE | A; TO 68100-18890-998 This part replaces 68116-18670-998.
68100-18890-998
Unavailable
19
NO DESCRIPTION AVAILABLE | A; TO 68100-18890-998 This part replaces 68126-18670-998.
68100-18890-998
Unavailable
20
NO DESCRIPTION AVAILABLE | B; Includes Item(s) 21 This part replaces 44110-18680-03G.
44110-18680-737
Unavailable
21
TAPE SET | B
68101-18810-61R
Unavailable
22
EMBLEM, FUEL TANK | K
68111-33000
Unavailable
23
EMBLEM, FUEL TANK | L
68111-33001
Unavailable
24
EMBLEM, FUEL TANK | M; TO 68111-33001 This part replaces 68111-33002.
68111-33001
Unavailable
26
NUT | K,L,M
09148-04005
Unavailable
28
CAP ASSY,FUEL T | K,L,M,A,B; Includes Item(s) 29 - 33 This part replaces 44200-33011.
44200-33012
Unavailable
30
PIN, CAP FRONT | K,L,M,A,B
44239-33010
Unavailable
31
WASHER | K,L,M,A,B
44238-33010
Unavailable
32
PIN, CAP LOCK | K,L,M,A,B
44233-33010
Unavailable
33
E RING | K,L,M,A,B
09383-02003
Unavailable
36
WASHER | K,L; 8.5x29x1.5
09160-08006
Unavailable
38
CUSHION, FUEL TANK REAR | K,L,M,A,B
44541-18000
Unavailable
40
SEAT | K,L; TO 5100-18641-403 This part replaces 45100-18640-403.
45100-18641-865
Unavailable
41
SEAT | M,A
45100-18641-403
Unavailable
41
SEAT | B; FROM 5100-18641-403
45100-18641-865
Unavailable
