Suzuki GT250 (1977) BRAKE SHOE (GT250K) Diagram

#

Description
Price

1

BOOT, MASTER CYLINDER This part replaces 59711-18400.

59711-49001

$7.51

2

UNION This part replaces 09360-10003.

09360-10017

$3.42

3

WASHER (10X15X1.5) This part replaces 09161-10005.

09161-10009

$1.84

4

NO DESCRIPTION AVAILABLE | TO 59480-18700 This part replaces 59480-18410.

59480-18700

Unavailable

5

GROMMET This part replaces 09308-14007.

09308-14009

Unavailable

6

GUIDE, BRAKE HOSE

59243-18401

Unavailable

7

NUT This part replaces 08312-32108.

08310-00107

$2.19

8

LOCK WASHER This part replaces 08321-21108.

08321-01107

$1.84

9

NO DESCRIPTION AVAILABLE | TO 59240-34011 This part replaces 59240-34010.

59240-34012

Unavailable

10

GROMMET, BRAKE HOSE

59244-18400

Unavailable

11

CLAMP, BRAKE HOSE

51456-18401

Unavailable

12

PLATE, HOSE CLAMP LOCKING

51457-18400

Unavailable

13

GROMMET

09308-10008

Unavailable

14

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

15

FRM CVR,SCREW(6 This part replaces 09128-06011.

09128-06092

$1.92

16

COVER, BRAKE PIPE

59280-18400

Unavailable

17

PIPE, BRAKE

59250-18600

Unavailable
