Suzuki GSXR50 (1987) REAR COMBINATION LAMP Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE | Includes Item(s) 2 - 3 This part replaces 35710-28B01.

35710-28B01-999

Unavailable

2

SOCKET

35718-28B00

Unavailable

3

BULB (6V,10/3W)

09471-06008

Unavailable

4

NUT This part replaces 08316-26066.

08316-1006B

$2.50

5

BRACKET, SEAT TAIL COVER

35730-28B00

Unavailable

6

SCREW (4x12) This part replaces 03541-04126.

03541-0412A

$1.49

7

BOLT, GEAR SHIFT LINK This part replaces 01107-06206.

01500-0620A

$1.78

8

WASHER (6.5X18X1.6) This part replaces 09160-06057.

09160-06109

$1.49

9

WASHER This part replaces 09160-14032.

09160-14059

$2.65

10

SPACER (6.5X9X9) This part replaces 09180-06011.

09180-06263

$2.03

11

CUSHION

09320-09031

Unavailable

12

CAP

09250-11003

$2.50

13

REFLEX REFLECTOR, REAR

35970-17300

Unavailable

14

WASHER (5.2X16X1)

09160-05013

$1.49

15

NUT This part replaces 08310-11056.

08310-0005A

$1.84
