Partiron

Suzuki GSXR50 (1987) GEAR SHIFTING Diagram

#

Description
Price

1

FORK, GEAR SHIFT NO.1

25211-09400

Unavailable

2

FORK, GEAR SHIFT NO.2

25221-09400

Unavailable

3

SPACER (6X9.8X6)

09180-06086

$2.50

4

SHAFT (6X9.8X6)

25411-09410

Unavailable

5

CAM, GEAR SHIFTING

25311-28B01

Unavailable

6

PLATE, STOPPER

25381-28B01

Unavailable

7

GUIDE, CAM

25382-35401

$1.49

8

ROLLER (4X13.8)

09261-04002

$1.72

9

STOPPER

08211-06221

Unavailable

10

BOLT This part replaces 01107-06166.

01500-0616A

$1.78

11

RETAINER, SHIFT CAM

25341-09400

Unavailable

12

SCREW

02122-06167

$1.49

13

STOPPER, SHIFT CAM

25350-09410

Unavailable

14

BOLT

09111-06041

$2.61

15

WASHER

08211-06121

$1.54

16

SPRING, SHIFT CAM STOPPER

25355-09400

Unavailable

17

ARM ASSY, GEAR SHIFTING | Includes Item(s) 18 - 20

25501-28B02

Unavailable

18

SPRING

09443-07030

Unavailable

19

SPRING This part replaces 09444-26022.

09444-26025

$5.33

20

SPACER (12X20X14)

09180-12113

Unavailable

21

OIL SEAL (12X22X9) This part replaces 09285-12002.

09285-12006

$6.32

22

STOPPER, GEAR SHIFT ARM

25671-36A00

$5.40

23

LEVER, GEAR SHIFTING

25610-28B01

Unavailable

24

RUBBER

25652-49300

$5.07

25

..BOLT This part replaces 01547-06205.

01547-0620B

$2.45

26

BODY, GEAR SHIFTING SWITCH

37720-09410

Unavailable

27

SCREW This part replaces 02112-05128.

02112-05127

$1.97

28

WASHER This part replaces 08322-21057.

08322-01057

$2.13

29

O RING (D:2.4,ID:26.2) This part replaces 09280-26003.

09280-26005

$2.30

30

CONTACT

09209-05011

$2.20

31

SPRING

09440-04010

$1.54
