Suzuki GSXR50 (1987) CYLINDER HEAD Diagram

#

Description
Price

1

HEAD, CYLINDER | Includes Item(s) 2

11110-09406

Unavailable

2

GUIDE, VALVE

11115-09470

Unavailable

3

GASKET, CYLINDER HEAD

11141-09403

Unavailable

4

PIN

09206-08001

$1.78

5

NUT

09159-06023

Unavailable

6

GASKET

09168-06017

$1.92

7

WASHER (6.5X14X2.3) This part replaces 09160-06017.

09160-06127

$2.30

8

SPARK PLUG (NGK,C6HA)

09482-00294

Unavailable

8

SPARK PLUG (ND,U20FS-L)

09482-00295-111

Unavailable

9

CAP, INSPECTION

11175-09400

Unavailable

10

O RING

09280-50007

$4.68

11

BOLT This part replaces 01517-06258.

01550-06257

$2.30

12

COVER, CYLINDER HEAD,RH

11134-09400

Unavailable

13

NO DESCRIPTION AVAILABLE This part replaces 11135-09401.

11135-09410

Unavailable

14

COVER, CYLINDER HEAD,LH

11121-09404

Unavailable

15

O RING (D:2.4,ID:73.5)

09280-70008

$8.10

16

BOLT This part replaces 01517-06208.

01550-06207

$2.30

17

BOLT This part replaces 01107-06257.

01500-06257

$1.97

18

PIPE, INTAKE

13111-28B00

Unavailable

19

INSULATOR, CARBURETOR

13129-28B00

Unavailable

20

NO DESCRIPTION AVAILABLE This part replaces 13125-28B00.

13125-28B00-H17

Unavailable

21

O RING (D:2.4,ID:23.7) This part replaces 09280-24005.

09280-24010

$5.64

22

BOLT

01547-06257

$2.03

23

.NUT This part replaces 08310-22067.

08310-00067

$2.13

24

NO DESCRIPTION AVAILABLE | OPT This part replaces 11400-28882.

11400-28887

Unavailable
