Suzuki GSX800FRQM5 (2025) STEERING STEM Diagram

#

Description
Price

1

BRACKET,UPPER (BLACK)

51311-25L10-291

$303.38

2

BOLT,BRACKET

51328-25L30

$3.40

3

BOLT,HANDLE HOLDER (8X35)

51321-27C40

$4.96

4

BRACKET,UNDER

51410-25L10

$436.47

5

.SEAL,STEERING LWR (30.1X56X4

51644-12C00

$9.44

6

.BEARING (30X55X17)

09265-30020

$44.41

7

CAP

51482-44H00

$17.83

8

CAP,STEERING STEM

51344-13K00

$11.78

9

NUT

51353-13K00

$10.67

10

WASHER

51356-13K00

$3.08

11

NUT,STEERING

51631-08D30

Unavailable

12

SEAL,STEERING UPR DUST

51643-01B10

$11.07

13

BEARING (25X47X15)

09265-25038

$45.57
