Description

Price

1

STAND, PROP

42310-19C01

Unavailable

2

SPRING, NO.1

09443-12036

$7.84

3

SPRING, NO.2

09443-19010

$6.51

4

BOLT

09111-10036

$4.82

5

SHIM

08221-12224

$1.96

6

NUT

09159-10097

$5.66

7

PEDAL, BRAKE

43110-19C02

Unavailable

8

ARM, BRAKE PEDAL ROD

43120-19C00

Unavailable

9

RUBBER

43151-04701

$5.80

10

WASHER, BRAKE BOSS

43212-04A00

$2.13

11

BOLT, FINAL GEAR CASE COVER This part replaces 01547-06253.

01547-0625B

$2.45

12

SPRING

09443-13028

$7.57

Suzuki GSX600FV (1997) STAND Diagram

STAND, PROP

SPRING, NO.1

SPRING, NO.2

BOLT

SHIM

NUT

PEDAL, BRAKE

ARM, BRAKE PEDAL ROD

RUBBER

WASHER, BRAKE BOSS

BOLT, FINAL GEAR CASE COVER This part replaces 01547-06253.

SPRING
