Suzuki GSX600FV (1997) HANDLE LEVER Diagram

#

Description
Price

1

GRIP, THROTTLE

57110-49501

$34.00

2

LEVER ASSY, BRAKE | Includes Item(s) 3 - 9 This part replaces 57300-32C01.

57300-32C10

$78.02

3

LEVER, ADJUST

57420-32C00

$28.92

4

KNOCKER This part replaces 57430-32C00.

57430-32C10

$60.37

5

SPRING

57438-32C00

$5.67

6

BOLT

57437-32C01

$8.60

7

NUT This part replaces 08319-31065.

08319-3106A

$2.03

8

BOLT, LEVER

57431-17C00

$7.11

9

NUT This part replaces 08316-10063.

08316-1006B

$2.50

10

SWITCH ASSY,FR BRAKE | Includes Item(s) 11 This part replaces 57460-17C00.

57460-14J02

$38.46

11

SCREW

57465-17C00

$2.19

12

GRIP, LH

57211-49500

$13.95

13

LEVER ASSY, CLUTCH | Includes Item(s) 14 - 20

57500-19C11

Unavailable

14

LEVER This part replaces 57620-19C01.

57620-27A31

$22.77

15

BOLT

57431-49110

$6.31

16

.NUT This part replaces 08319-21065.

08319-2106B

$2.32

17

ADJUSTER

57441-44400

$6.28

18

NUT This part replaces 57442-44400.

57442-11010

$2.79

19

BOLT

01204-06204

$2.72

20

.WASHER This part replaces 08322-01063.

08322-0106B

$2.26
