Suzuki GSX600F (2006) FRAME COVER (MODEL K6) Diagram

#

Description
Price

1

COVER,FRAME,R | FOR 019 This part replaces 47110-08FA0-019.

47111-08FA0

$222.77

1

COVER,FRAME,R | FOR CWH; Includes Item(s) 2 - 4 This part replaces 47110-08FA0-YBD.

47111-08FA0

$222.77

2

EMBLEM,FRAME CO | FOR 019 This part replaces 68131-39F00-YD8.

68131-39F01-YD8

Unavailable

2

EMBLEM (BLACK) | FOR YBD

68131-39F00-019

Unavailable

3

TAPE, FRAME COVER RH | FOR 019

68135-08F30-DBJ

Unavailable

3

TAPE, FRAME COVER RH | FOR YBD

68135-08F30-DBK

Unavailable

4

TAPE, FRAME COVER LH | FOR 019

68145-08F30-DBJ

Unavailable

4

TAPE, FRAME COVER LH | FOR YBD

68145-08F30-DBK

Unavailable

5

COVER, FRAME LOWER

47321-08FA0

Unavailable

6

SCREW, UPPER

09136-06105

$1.97

7

SPACER

09180-06286

$2.50

8

CUSHION

09320-10045

$3.76

9

CUSHION, FRONT

09320-08028

$3.04

10

CUSHION, CENTER

09320-08018

$3.04

11

CLIP (BLACK)

09409-08308-5ES

$1.97

12

CUSHION (10X30X2)

44894-24A00

$1.72
