Suzuki GSX1300RRQM3 (2023) RADIATOR Diagram

#

Description
Price

1

RADIATOR,WATER

17710-10L00

$562.28

2

CAP,RADIATOR (1.1)

17730-14G00

$42.83

3

BOLT (6X25)

09118-06097

$2.50

4

SPACER (6.5X10X12)

09180-06290

$2.35

5

CUSHION

09320-10051

$2.99

6

BRACKET,RADIATOR

17750-10L00

$12.52

7

BOLT

01550-0612A

$1.97

8

FAN ASSY,RADIATOR,L

17810-10L00

$244.87

9

FAN ASSY,RADIATOR,R

17820-10L00

$244.87

10

BOLT,FAN ASSY

17711-10L00

$2.58

11

NUT,RADIATOR FAN

17802-14F00

$3.38

12

SHIELD,RADIATOR HEAT

17771-10L00

$34.05

13

TAPE,RR FENDER (30X75X0.2)

63131-10F00

$14.02
