Suzuki GSX1300R (2007) TURNSIGNAL LAMP (MODEL K5/K6/K7) Diagram

#

Description
Price

1

LAMP ASSY, FRONT TURNSIGNAL RH

35601-24F10

Unavailable

1

LAMP ASSY, FRONT TURNSIGNAL LH | Includes Item(s) 2 - 6

35602-24F10

Unavailable

2

LAMP UNIT, RH

35610-24F10

$81.43

3

LAMP UNIT, LH

35630-24F10

Unavailable

4

SOCKET & CORD RH

35618-24F10

Unavailable

5

SOCKET & CORD LH

35638-24F10

Unavailable

6

BULB (12V,21W)

09471-12186

$16.18

7

SCREW

03541-0516B

$1.82

8

LAMP ASSY, REAR TURNSIGNAL RH

35603-24F30

Unavailable

8

LAMP ASSY, REAR TURNSIGNAL LH | Includes Item(s) 9 - 11

35604-24F30

$147.30

9

LAMP UNIT

35610-24F30

$46.13

10

SCREW This part replaces 03242-04123.

03242-0412B

$3.23

11

BULB (12V,21W)

09471-12186

$16.18

12

SPACER, REAR TURNSIGNAL LAMP

35695-17C00

$3.86

13

WASHER (10.5X30X2.3)

09160-10501

$2.40

14

NUT

08310-0010B

$2.95

15

RELAY ASSY,TURNSIGNAL LAMP This part replaces 38610-03F00.

38610-03F01

$85.27
