Suzuki GSX1300R (2007) FRAME COVER (GSX1300RZK6) Diagram

#

Description
Price

1

COVER, FRAME (WHITE) | Includes Item(s) 2 - 6

47110-24F90-YC3

Unavailable

2

TAPE, RH NO.1

68135-24F20-DEU

$28.13

3

TAPE, LH NO.1

68145-24F20-DEU

Unavailable

4

TAPE, RH

68135-24F30-DEV

$45.93

5

TAPE, LH

68145-24F30-DEV

Unavailable

6

EMBLEM,"SUZUKI" This part replaces 68281-24F10-YD8.

68281-24F11-YD8

$9.60

7

COVER, FRAME HEAD RH

47511-24F10

Unavailable

8

COVER, FRAME HEAD LH

47521-24F00

$38.72

9

CLIP, LH (BLACK)

09409-06314-5PK

$2.78

10

SCREW (4x12) This part replaces 03541-04123.

03541-0412A

$1.49

11

SCREW This part replaces 09139-06087.

09139-06126

$4.04

12

CUSHION

09320-09016

$1.97

13

CUSHION, REAR

47161-27E00

$10.32

14

SCREW, UPPER

09136-06105

$1.97

15

SPACER

09180-06288

$2.06

16

CUSHION

09320-10045

$3.76

17

CLIP, LOWER (BLACK)

09409-06314-5PK

$2.78

18

COVER,FRAME CEN This part replaces 47311-24F00-YC3.

47311-24F00

$43.78

19

CUSHION, UPPER FRONT

47191-24F00

$5.17

20

CUSHION, PILLION HANDLE REAR

47191-24F30

$5.36

21

WASHER,FRAME COVER This part replaces 47190-24F20.

47190-24F21

$9.94

22

CLIP (BLACK)

09409-06314-5PK

$2.78

23

CUSHION, CENTER

47191-24F20

$7.22
