Suzuki GSX1100GP (1993) REAR COMBINATION LAMP Diagram

#

Description
Price

1

LAMP ASSY, REAR COMBINATION | Includes Item(s) 2 - 7A

35710-26D00

Unavailable

2

LENS, LICENSE

35912-26D00

Unavailable

3

GASKET, LICENSE

35913-26D00

Unavailable

4

SCREW This part replaces 03211-04126.

03211-0412A

$2.23

5

BULB (12V,21/5W) This part replaces 09471-12083.

09471-12128

$6.73

6

.BULB (12V5W) This part replaces 09471-12081.

09471-12216

$5.36

7

SOCKET ASSY

35718-26D00

Unavailable

7A

CUSHION

56314-16B00

Unavailable

8

NUT COWL This part replaces 94484-32B00.

94484-24F00

$4.03

9

SCREW, REAR This part replaces 02142-15205.

02142-0520B

$1.78

10

BRACKET, LICENCE PLATE

35927-48B30

$14.20

11

SCREW This part replaces 02112-06164.

02112-0616A

$1.49

12

WASHER This part replaces 09160-06031.

09160-06125

$1.91

13

NUT This part replaces 08316-16066.

08316-1006B

$2.50

14

CUSHION

09321-06023

$2.50

15

REFLECTOR, REAR This part replaces 35970-00A21.

35970-00A10

Unavailable

16

NUT This part replaces 08316-26056.

08316-2005A

$2.19

17

BRACKET, REAR

35977-12C00

Unavailable

18

SCREW (4x12) This part replaces 03541-04125.

03541-0412A

$1.49

19

REFLECTOR, REAR This part replaces 35970-00A21.

35970-00A10

Unavailable

20

.NUT | MODEL M/N This part replaces 08310-22055.

09140-05006

$2.19

20

NUT | MODEL P This part replaces 08310-11056.

08310-0005A

$1.84
