Ski-Doo GSX Sport 600, 2010 Steering Wiring Harness Diagram

#

Description
Price

1

LH Housing

515177022

$213.82

2

Start/RER Button

515176088

$18.43

3

Switch Housing Plate

515175926

$17.66

4

Torx Screw #8-18

250000263

$1.02

5

Emergency Stop Switch | Includes 91 to 91a

515177362

$84.54

7

Kill Switch Support

515176825

$8.60

8

Torx Screw #8-18

250000263

$1.02

9

Steering Wiring Harness Ass'y | Includes 3200 to 3200n

515176995

$106.89

10

Male Terminal Housing, 8 Circuits

515175817

$8.57

11

Male Terminal Housing, 6 Circuits

515175662

$8.57

12

Heating Element

506152422

$102.28

13

LOW TEMPERATURE TUBING 1/2? 3000MM LONG - Call your local BRP dealership

219704427

Unavailable

14

Insulant

506153178

$10.23

15

Was 293550004 Dielectric Grease, 150 g

219704453

$37.66

A

Tie-Rap 180 mm

414115200

$0.09

B

Tie Wrap 368 mm

293750008

$0.85

C

Tie Wrap 142 mm

293750002

$0.88

D

Tie-Rap 173 mm

293750009

$0.85

E

Tie Wrap 94 mm | 4X4

293750001

$0.83
