Suzuki GSX-S1000XRREM5 (2025) MUFFLER Diagram

#

Description
Price

1

EXHAUST

14100-48K30

$3,021.52

2

.GASKET,EXHAUST PIPE

14181-04K00

$7.59

3

BRACKET,EXH SPRT

14770-48K00

$33.47

4

BOLT

09116-08176

$7.90

5

BOLT (8X25)

09106-08178

$2.97

6

GUIDE COMP,EXH VALVE CABLE

14250-48K00

$28.38

7

SPACER (8.6X12X24.2)

09180-08152

$5.26

8

CUSHION (12X30X24)

09320-12077

$10.78

9

BOLT (8X20)

09135-08007

$3.18

10

BOLT (8X40)

09106-08162

$5.17

11

PULLEY,CONTROLLER

11269-18G01

$32.50

12

CABLE,EXH VALVE NO.1

11276-48K10

$47.67

13

CABLE,EXH VALVE NO.2

11277-48K10

$47.67

14

BRACKET,EXHAUST VALVE CABLE

14250-21H00

$11.18

15

GUIDE,EXHAUST VALVE CABLE

14252-14J00

$8.32

16

BOLT

01547-0516A

$1.68

17

NUT (6X12)

08316-1006A

$2.19

18

BODY, MUFFLER

14310-48K10-H01

$440.08

19

CLAMP,MUFFLER CONNECTOR

14459-47H00

$27.51

20

CONNECTOR,MUFFLER

14771-24F01

$34.07

21

BOLT (8X45)

09106-08195

$6.72

22

BOLT (8X40)

09106-08162

$5.17

23

WASHER (8.5X30X2.3)

09160-08503

$2.53

24

SPACER (8.6X12X24.2)

09180-08152

$5.26

25

CUSHION (12X30X24)

09320-12048

$4.62

26

NUT

08316-1008A

$2.47

27

COVER,MUF FR

14780-48K50

$237.42

28

SHIELD, MUF COVER HEAT FR

14784-48K00

Unavailable

29

GROMMET

14795-10FA0

$5.26

30

SCREW (6X12)

09139-06128

$5.20

31

CUSHION

09320-04011

$6.75

32

CUSHION (8.4X18X6)

09320-08066

$7.44

33

COVER, MUF RR

14791-04K22

$96.55

34

BOLT

09116-06528

$5.27

35

SENSOR,OXYGEN

18213-25L00

$232.57

36

CLAMP (L:145)

09407-14407

$2.80
