Description

Price

1

COCK ASSY, FUEL | MODEL J/K This part replaces 44300-17C00.

44300-17CVV

$269.02

1

COCK ASSY, FUEL | MODEL L; Includes Item(s) 2 - 5 This part replaces 44300-17C01.

44300-17CVV

$269.02

2

O RING

44305-17C00

$7.85

3

LEVER

44306-17C00

$16.10

4

SCREW This part replaces 02112-04126.

02112-0412A

$1.49

5

LOCK WASHER This part replaces 08321-21046.

08321-0104A

$1.84

6

BOLT This part replaces 09128-06006.

09128-06057

$1.65

7

GASKET

09168-06026

$3.10

8

HOSE(7X10.2X600 This part replaces 09352-70103-600.

09352-70104-600

$5.63

9

SPRING | MODEL J/K This part replaces 09440-13020.

09440-13051

$10.76

9

SPRING | MODEL L

09440-13047

$4.82

10

CLIP

09401-10402

$2.42

11

CLIP This part replaces 09401-10201.

09401-10201-XC0

$2.19

12

LABEL, FUEL | MODEL J/K

44395-17C00

Unavailable

Suzuki GSX-R750L (1990) FUEL COCK Diagram
