1987 Suzuki GSX-R750G Steering Stem Diagram

← All diagrams

Find the part on the Steering Stem diagram for your 1987 Suzuki GSX-R750G, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1987 Suzuki GSX-R750G Steering Stem Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

HEAD, STEERING STEM (BLACK)

51311-27A00-291

1
Out of stock

2

STEM, STEERING | Includes Item(s) 3

51410-27A10

1
Out of stock

3

1

$72.93

In stock

4

1

$35.80

In stock

5

1

$35.80

In stock

6

1

$7.13

In stock

7

BOLT, UPPER

51352-00A00

2
Out of stock

8

BOLT, L This part replaces 07110-10408.

07130-1040B

2
Out of stock

9

NUT, STEERING STEM

51631-28000

1

$19.60

In stock

10

DUST COVER, STEERING UPPER

51643-27A00

1
Out of stock

11

BEARING

09265-25008

1

$61.43

In stock

12

LOCK ASSY, STEERING

51900-08014-KEY

1
Out of stock

13

LOCK WASHER This part replaces 08321-21057.

08321-0105A

2
Out of stock

14

2

$2.12

In stock
