Suzuki GSX-R750G (1987) REAR SHOCK ABSORBER Diagram

#

Description

Price

1

ABSORBER ASSY, REAR SHOCK | MODEL G; Includes Item(s) 2 - 5 This part replaces 62100-27A00.

62100-27A50

Unavailable

2

BEARING, REAR (10x24x14.5) This part replaces 62175-43400.

62175-00B00

$57.58

3

RING, STOPPER This part replaces 62277-14200.

62657-34A01

$2.06

4

DUST SEAL

62226-00A00

Unavailable

5

COLLAR

62684-00A00

Unavailable

6

ABSORBER ASSY, REAR SHOCK | MODEL H; Includes Item(s) 7 - 8

62100-27A50

Unavailable

7

DUST SEAL

62226-27A20

$11.37

8

COLLAR

62684-27A50

Unavailable

9

BOLT, UPPER

62311-08300

Unavailable

10

BOLT, LOWER

62648-14500

$4.09

11

NUT

08319-31107

$2.73

12

WASHER, UPPER

62321-27A00

Unavailable
