Suzuki GSX-R750G (1987) GEAR SHIFTING Diagram

#

Description
Price

1

FORK, GEAR SHIFT NO.1 This part replaces 25211-27A00.

25211-27A12

Unavailable

2

FORK, GEAR SHIFTING NO.2

25221-27A01

Unavailable

3

FORK, GEAR SHIFTING NO.3

25231-27A00

Unavailable

4

SHAFT, GEAR SHIFTING FORK

25411-27A00

$33.02

5

CAM, GEAR SHIFT This part replaces 25310-27A01.

25310-27A03

Unavailable

6

GEAR, GEAR SHIFT CAM DRIVEN This part replaces 25322-31301.

25322-31310

$30.40

7

PAWL, GEAR SHIFT NO.1 | MODEL G This part replaces 25323-34200.

25323-34201

$6.61

7

PAWL, GEAR SHIFT NO.1 | MODEL H

25323-34201

$6.61

8

PAWL, GEAR SHIFT NO.2 | MODEL G This part replaces 25324-34200.

25324-34201

$6.80

8

PAWL, GEAR SHIFT NO.2 | MODEL H

25324-34201

$6.80

9

PIN

09261-05003

$1.69

10

SPRING

09440-04003

$1.48

11

LIFTER,GEAR SHI This part replaces 25331-31301.

25331-31310

Unavailable

12

SCREW This part replaces 02122-06128.

02122-06127

$1.83

13

GUIDE, CAM

25341-27A00

Unavailable

14

SCREW This part replaces 02122-06128.

02122-06127

$1.83

15

BEARING, RH

09263-43001

$36.05

16

BEARING This part replaces 08110-69050.

08113-69050

$32.64

17

CIRCLIP This part replaces 08331-41428.

08331-41429

$2.51

18

STOPPER, CAM

25350-27A00

$19.03

19

SPRING

09443-09031

Unavailable

20

SHAFT, STOPPER

25353-27A00

Unavailable

21

GASKET

09168-10002

$1.96

22

CIRCLIP This part replaces 08331-31086.

08331-31089

$1.77

23

PLATE, STOPPER

25381-38400

Unavailable

24

PIN This part replaces 06211-04063.

04221-04069

$2.30

25

CIRCLIP, REAR FINAL DRIVE This part replaces 08331-31258.

08331-31256

$1.09

26

SHAFT, GEAR SHIFT This part replaces 25510-27A00.

25510-19C01

Unavailable

27

SPRING

09444-26017

$5.00

28

STOPPER, ARM This part replaces 25671-01000.

25671-01011

$4.09

29

OIL SEAL (12X22X9) This part replaces 09285-12002.

09285-12006

$5.70

30

WASHER (12.5X26X1.6) This part replaces 09160-12020.

09160-12089

$1.99

31

CIRCLIP This part replaces 09384-12001.

08331-3112A

$1.77

32

ARM,GEAR SHIFT This part replaces 25520-33301.

25520-19C03

$32.63

33

ROD, GEAR SHIFT LINK This part replaces 25525-27A10.

25525-27A30

Unavailable

34

NUT

09140-06011

$1.37

35

.NUT This part replaces 08310-11067.

08310-00067

$1.83

36

BOLT This part replaces 01107-06257.

01500-06257

$1.97

37

LEVER ASSY, GEAR SHIFTING | Includes Item(s) 38

25600-27A00

Unavailable

38

COVER

43151-04701

$5.46

39

WASHER (12.5X20X1)

09160-12011

$1.48

40

CIRCLIP This part replaces 08331-31128.

08331-3112A

$1.77

41

BODY, GEAR SHIFTING SWITCH | MODEL G

37720-09300

Unavailable

41

BODY, GEAR SHIFTING SWITCH | MODEL H

37720-48B00

$66.48

42

GROMMET, LEAD WIRE This part replaces 33885-27A00.

33885-27A01

$4.72

43

O RING (D:2.4,ID:36.2)

09280-36001

$3.01

44

SCREW

09125-05102

$1.61

45

LOCK WASHER This part replaces 08321-21057.

08321-0105A

$1.83

46

WASHER This part replaces 08322-21057.

08322-01057

$1.86

47

CONTACT

09209-05011

$2.02

48

SPRING

09440-04010

$1.52

49

SHAFT, LEVER

25617-20A00

$29.52

50

NUT, WHEEL SET This part replaces 08316-16108.

08316-10107

$2.38
